IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type MPN:LC1G4004EHEN

• The IEC Magnetic Contactor is a 4-pole, electrically operated switching device that conforms to IEC standards for controlling power circuits. It includes auxiliary contacts as specified and operates within the indicated coil voltage range. The unit uses a spring-type terminal connection, is part of the TeSys Giga series, and is rated for operation within the specified voltage range up to 1000V AC and has an IP20 ingress protection rating (note: this does not imply safety or suitability for all environments).

  - Item: IEC Magnetic Contactor

• - Poles: 4
• - Auxiliary contacts: 2 (1NC/1NO)
• - Coil voltage: 48V-130V AC/DC
• - Frequency: 50/60 Hz
• - Embedded surge suppressor: No
• - Phase: Single
• - Mounting style: Plate
• - Terminal connection type: Spring Type
• - IP rating: IP20
• - Maximum voltage rating: 1000V AC
• - Series: TeSys Giga
• - Dimensions: Depth 4.8 in
• Height 8.86 in
• Width 7.28 in
• - Mechanical operating durability: 8,000,000 cycles
• - Maximum operating temperature: 140°F
• - Minimum operating temperature: -13°F
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
• - Full Load Amps – Inductive: 490 A
• - Full Load Amps – Resistive: 550 A
• - Full Load Current – Inductive: 400 A
• - Full Load Current – Resistive: 550 A
• - Includes Auxiliary Contacts: Yes
