IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type MPN:LC1G150EHEN
Free Shipping
In Stock
The Schneider IEC Magnetic Contactor is a versatile and reliable switching device designed for use in industrial control panels. Suitable for a wide range of applications, including motor control, lighting, and other industrial loads, this compact and modular unit offers standardized sizing and interchangeability. With a robust design and high current ratings, it can handle demanding tasks with ease. Its compact size and standardized design make it easy to integrate into existing systems, reducing complexity and increasing efficiency. Ideal for use in various industries, including manufacturing, energy, and infrastructure.
Top product features:
- The IEC Magnetic Contactor has an electromagnetic coil that uses AC/DC power to open or close contacts for switching motors, lighting, and other industrial loads.
- It features 2 auxiliary contacts, with 1 normally closed (NC) and 1 normally open (NO), for additional control and functionality.
- The contactor is designed with a compact and modular IEC-style unit, allowing for standardized sizing and interchangeability in control panels.
Top product applications:
- Motor Control Circuits
- Industrial Lighting Control
- Power Distribution Systems
The IEC Magnetic Contactor is an electrically operated switching device rated for operation within the specified IEC standards. It uses an electromagnetic coil to open or close contacts for switching motors, lighting, and other industrial loads. This IEC-style unit is compact and modular, with standardized sizing and interchangeability for use in control panels.
- Coil Voltage: 48V-130V AC/DC
- - Auxiliary Contacts: 2 total (1NC/1NO)
- - Contactor Style: IEC
- - Embedded Surge Suppressor: No
- - Frequency: 50/60 Hz
- - Full Load Amps (Inductive): Rated for a maximum inductive current of 230 A under specified conditions
- - Full Load Amps (Resistive): Rated for a maximum resistive current of 275 A under specified conditions
- - Full Load Current (Inductive): Rated for a maximum continuous inductive current of 150 A within its specifications
- - Full Load Current (Resistive): Rated for a maximum continuous resistive current of 275 A within its specifications
- - IP Rating: IP20
- - Number of Poles: 3
- - Phase: Single
- - Mounting Style: Plate
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Terminal Connection Type: Spring Type
- - Maximum Voltage Rating: 1000V AC
- - Mechanical Operating Durability: Has an expected mechanical lifespan based on typical usage cycles
- actual lifespan may vary depending on operating conditions
- - Maximum Operating Temperature: 140 Degrees F
- - Minimum Operating Temperature: -13 Degrees F
- - Overall Dimensions: 7.6 in (Depth) x 7.6 in (Height) x 4.25 in (Width)
- - Item: IEC Magnetic Contactor
- - Series: TeSys Giga
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.16
- Package Width: 9.25
- Package Height: 9.84
- Package Weight: 10.56
