IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 3 P, Spring Type MPN:LC1G150BEEA

• The IEC Magnetic Contactor is a 3-pole, electrically operated switching device rated for operation within specified electrical parameters. It is equipped with a coil rated for 24V-48V AC/DC within specified voltage ranges to operate the main contacts and contains auxiliary contacts (1NC/1NO) as specified, with spring-type terminal connections and plate mounting. This TeSys Giga series device has an IP20 enclosure. It is rated for operation up to 1000V AC within applicable standards and designed for use at frequencies of 50/60 Hz as per specifications. It does not include an embedded surge suppressor and is specified for single-phase operation within a -13°F to 140°F temperature range. The unit has an expected mechanical lifespan based on testing standards

• actual performance may vary and conforms to relevant safety and performance standards as listed. Overall dimensions are 7.6 in depth, 10.04 in height, and 4.25 in width.

  - Auxiliary contacts: Contains auxiliary contacts (1NC/1NO) as specified

• - Coil voltage: 24V-48V AC/DC
• - Contactor style: IEC
• - Embedded surge suppressor: No
• - Frequency: 50/60 Hz, as per specifications
• - Full Load Amps (Inductive): 230 A
• - Full Load Amps (Resistive): 275 A
• - Full Load Current (Inductive): 150 A
• - Full Load Current (Resistive): 275 A
• - IP rating: IP20
• - Mounting style: Plate
• - Number of poles: 3
• - Phase: Single
• - Series: TeSys Giga
• - Terminal connection type: Spring Type
• - Maximum voltage rating: Up to 1000V AC within applicable standards
• - Maximum operating temperature: 140 Degrees F
• - Minimum operating temperature: -13 Degrees F
• - Standards: Conforms to relevant safety and performance standards as listed (CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1)
• - Item: IEC Magnetic Contactor
• - Overall depth: 7.6 in
• - Overall height: 10.04 in
• - Overall width: 4.25 in
