IEC Magnetic Contactor, 1NO, 48V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K1210E7
Free Shipping
In Stock
The Schneider IEC Magnetic Contactor is a reliable and versatile device designed for a wide range of industrial applications. Suitable for use in various settings, it operates on a coil voltage of 48V AC and features a compact design, making it easy to integrate into existing systems. With its non-reversing, three-pole configuration and 1NO auxiliary contact, it provides efficient control and monitoring capabilities. Ideal for applications such as motor control, lighting, and heating systems, this contactor offers improved safety, reduced maintenance, and increased productivity, making it a valuable addition to any industrial setup.
Top product features:
- Operates at frequencies of 50/60 Hz.
- Has full load amps-inductive of 12 A and full load amps-resistive of 20 A.
- Includes one auxiliary contact.
Top product applications:
- Automotive Lighting Systems
- Industrial Control Panels
- HVAC Systems
The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a non-reversing, three-pole device with an auxiliary contact form of 1NO. It operates on a coil voltage of 48V AC and has a maximum voltage rating of 690V AC. The contactor is designed for DIN Rail or Plate mounting styles and features insulation resistance properties. With its compact dimensions (2.24 in depth, 2.28 in height, and 1.77 in width), it fits comfortably within various industrial settings.
Key Features:
- - Operates at frequencies of 50/60 Hz.
- - Has full load amps-inductive of 12 A and full load amps-resistive of 20 A.
- - Includes one auxiliary contact.
- - Rated as IP20, indicating its ability to resist ingress of solid objects up to 12mm
- it does not have a rating for water resistance.
- - Mechanical operating durability is tested up to ten million cycles and electrical operating durability has been tested within the range of 300,000 (AC-1) to over a million (AC-3 & AC-3e).
- - Complies with multiple standards including CSA C22.2 No 60947-4-1, EN/IEC 60947-4-, GB/T14048.4 JIS C8201 -4 -1 UL60947 -4 -1
- -The terminal connection type is Screw Clamp250 which is designed for connecting wires and devices.
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.56
- Package Width: 2.44
- Package Height: 1.89
- Package Weight: 0.39
