IEC Magnetic Contactor, 1NC/1NO, 240V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1D65AU7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for motor control and resistive load applications. Its non-reversing design ensures safe and precise control, while its 1NC/1NO auxiliary contact configuration provides flexibility for various control schemes. The contactor's compact size and screw clamp terminals make it easy to install in limited spaces, and its insulation voltage rating of 600/690V ensures reliable operation. Suitable for use in a wide range of industries, including manufacturing, HVAC, and power generation, this contactor is a valuable addition to any control panel or system.
Top product features:
- Operates at a frequency of 50/60 Hz.
- Has full load amps-inductive of 65 A and full load amps-resistive of 80 A.
- Includes Everlink Power Connections for enhanced connectivity.
Top product applications:
- Motor control
- Resistive load applications
- General industrial control
The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a non-reversing, three-phase contactor intended for use in motor control and resistive load applications. It operates with a coil voltage of 240V AC and features screw clamp terminals for electrical connection. The contactor has an auxiliary contact configuration of 1NO/1NC, which means it includes one normally open and one normally closed auxiliary contact. This product is compatible with DIN rail or plate mounting styles, allowing installation flexibility.
Key Features:
- - Operates at a frequency of 50/60 Hz.
- - Has full load amps-inductive of 65 A and full load amps-resistive of 80 A.
- - Includes Everlink Power Connections for enhanced connectivity.
- - Comes with protective cover to shield the device from external factors.
- - Tested to endure impulse voltages up to 6 kV under controlled conditions.
- - Insulation voltage rating is between 600/690V as per manufacturer's specifications. Actual performance may vary depending on specific usage conditions.
- - Mechanical durability has been tested up to six million cycles under standard test conditions. Actual lifespan may vary based on usage and environmental factors.
- - Has a specified operating temperature range of -40 Degrees F to 140 Degrees F. Performance outside these ranges has not been evaluated by the manufacturer.
- - Overall dimensions: Depth -4.72 inches, Height -4.8 inches, Width -2.17 inches
- compact size allows easy installation in limited spaces.
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.00
- Package Width: 5.50
- Package Height: 2.50
- Package Weight: 2.11
