Socket, General Purpose Relay, Square, 15 A, 14 Pins, Quick Connect MPN:8501RS44V20
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0976814
Socket, General Purpose Relay, Square, 15 A, 14 Pins, Quick Connect
The Schneider General Purpose Relay is a versatile and reliable solution for a wide range of applications. This square-shaped relay can be easily installed in tight spaces, making it ideal for use in industrial control panels, machine automation, and process control systems. With a current rating of 15A and a contact rating of up to 277V AC, it can handle high-power loads with ease. The quick-connect design and push-to-test method simplify maintenance and troubleshooting, while the mechanical flag indicator provides visual confirmation of relay status. Suitable for use in a variety of industries, including manufacturing, oil and gas, and food processing.
Top product features:
- Square base shape design
- Quick-Connect electrical connection
- 4PDT contact form with mechanical flag status indicator
Top product applications:
- Industrial control panels
- Automotive electronics
- Medical equipment control systems
General Purpose Relay, Base Shape Square, Coil Voltage 120V AC, Contact Form 4PDT, Current Rating 15 A, Electrical Connection Quick-Connect, Flat Pin Width 0.18 in, Number of Pins 14, Pin Shape Flat, Sealing Enclosed, Status Indicator Mechanical Flag, Contact Rating (AC) 15 A @ 277V, Contact Rating (DC) 10 A @ 28V, Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 3/4 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.07 in, Body Height 1.57 in, Body Width 0.83 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.50
- Package Width: 2.50
- Package Height: 1.90
- Package Weight: 0.16
Product info last updated on March 16, 2026 5:04pm UTC
Category: Industrial Electrical Controls and Automation
