IEC Magnetic Contactor, 1NC/1NO, 24V DC, 4 P, Non-Reversing, Screw Clamp MPN:LC1D098BD
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for controlling power circuits in industrial and commercial applications. With a 24V DC coil and 4-pole, non-reversing design, it provides precise control and safety features. The device is suitable for use in a variety of settings, including manufacturing, HVAC, and lighting control systems. Its screw clamp terminals and protective cover ensure easy installation and maintenance. By choosing this magnetic contactor, users can benefit from improved reliability, reduced downtime, and enhanced overall system performance.
Top product features:
- The device uses screw clamp terminals for power and control wiring.
- It has a 1NC/1NO auxiliary contact.
- It is rated for operation within specified IEC standards and intended for controlling power circuits.
Top product applications:
- Industrial Automation Systems
- Motor Control Centers
- Power Distribution Units
The Schneider Electric IEC Magnetic Contactor is a 4-pole, non-reversing, electrically operated switch rated for operation within IEC standards and intended for controlling power circuits. It has a 24 V DC coil and a 1NC/1NO auxiliary contact. The device uses screw clamp terminals for power and control wiring and is part of the TeSys Deca range (LC1D). It includes a protective cover and is rated for use with resistive loads within specified IEC standards.
Key features
- - Coil voltage: 24 V DC
- coil protection: includes a diode suppression device as specified
- does not imply guaranteed protection against all conditions
- - Poles and contacts: 4P
- 2 NO + 2 NC per pole
- 1NC/1NO auxiliary contact
- - Electrical connections: Screw clamp terminals for power and control circuits
- - Protection and housing: IP20 front face
- protective cover included
- complies with UL 94 V1 flammability classification (does not guarantee fire safety)
- protective treatment THIEC 60068-2-30
- - Mechanical/physical: Width 45 mm, Height 85 mm, Depth 99 mm
- Net weight 0.525 kg
- mounting on Plate and Rail
- - Ratings and capability: rated for operation within specified voltage and current ranges per product specifications
- - Load and endurance: rated load capacities based on testing under standard conditions, not guarantees of performance under all circumstances
- - Additional specs: impulse withstand voltage: capable of withstanding impulse voltages up to the specified level when used within ratings
- Series LC1D
- Range TeSys Deca
- Poles: 4P
- Auxiliary contact configuration: 1NC/1NO
- Mounting: Plate, Rail
- Standards cover IEC 60947-4-1/5-1 and related certifications
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 16
- Unit of Measure: EA
- Package Length: 15.70
- Package Width: 11.80
- Package Height: 5.90
- Package Weight: 20.60
