IEC Magnetic Contactor, 1NC/1NO, 120V AC, 4 P, Screw Clamp MPN:LC1DT80AG7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for switching resistive load power circuits in various applications. Suitable for use in industrial settings, this 4-pole device features a 120V AC coil and 1NC/1NO auxiliary contact, providing a high level of control and flexibility. Its compact design and robust construction make it ideal for mounting on plate or rail, while its protective covers and compatible connections ensure safe and reliable operation. Perfect for use in control panels, machine tools, and other industrial equipment, this magnetic contactor offers a range of benefits, including reduced energy consumption and increased productivity.
Top product features:
- The product has 4 main NO poles for switching resistive load power circuits.
- It has a 1NC/1NO auxiliary contact for additional control functionality.
- The product can withstand short-duration current surges of up to 640 A (10 s) in the power circuit.
Top product applications:
- Industrial Automation Systems
- Electrical Distribution Panels
- Motor Control Centers
The Schneider Electric IEC Magnetic Contactor is a 4-pole, 120 V AC coil device (4P) with a 1NC/1NO auxiliary contact. It is rated for switching resistive load power circuits within specified parameters and belongs to the TeSys Deca LC1D product series. The unit mounts on plate or rail and includes protective covers and compatible power connection options as specified, with control circuit terminals in screw clamps and power circuit connections via EverLink BTR screw connectors.
Key features
- - Coil voltage: 120 V AC
- - Poles and contacts: 4 main NO poles
- auxiliary contacts 1 NC / 1 NO (2 total)
- - Series/range: TeSys Deca LC1D product series
- - Utilisation category: AC-1
- Overvoltage category CAT III
- - Rated currents: rated for continuous operation up to 80 A in accordance with applicable standards under specified conditions
- - Rated making capacity: up to the listed values under standard test conditions
- - Short-time withstand current: capable of withstanding short-duration current surges within specified limits as tested according to standards (Power circuit up to 640 A (10 s)
- 900 A (1 s)
- signalling circuit up to 140 A (100 ms))
- - IP rating: IP20 front face
- - Environmental: Mercury Free, PVC Free, Toxic Heavy Metal Free, Pollution Degree 3
- - Ambient temperature: rated for operation within ambient temperatures from -40°C up to the maximum specified temperature with appropriate derating as per specifications
- - Protection: Includes protective covers
- - Dimensions and weight: Height 122 mm
- Width 70 mm
- Depth 120 mm
- Net weight 1.15 kg
- - Connections: Control Circuit - Screw Clamp Terminals
- Power Circuit - EverLink BTR Screw Connectors
- - Heat and power: Power dissipation per pole 10.2 W (AC-1)
- Inrush VA 140 VA
- Hold VA 13 VA
- - Impedance and electrical ratings: Impedance 1.6 mΩ
- Impulse withstand voltage 6 kV
- - Standards: EN 60947-4-1
- EN 60947-5-1
- IEC 60947-4-1
- IEC 60947-5-1
- UL 508
- CSA C22.2 No 14
- others listed
- - Additional: Includes Everlink Power Connections
- Range = TeSys
- Protective treatment THIEC 60068-2-30
- Fire ratings UL 94 V1
- Fire resistance 850°C IEC 60695-2-1
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 2.40
