IEC Magnetic Contactor, 4NO, 24V DC, 4 P, Solder Pin MPN:LP1K090045BD

• The Schneider Electric IEC Magnetic Contactor is a 4-pole, 4 normally open (4 NO) device with a 24 V DC coil and solder-pin terminals. It is intended for switching resistive loads within specified ratings and is part of the TeSys range for PCB mounting. It operates within the specified temperature ranges.

  - Coil voltage: 24 V DC

• - Poles/contacts: 4P, 4 NO
• - Terminal connections: Solder pins
• - Application: Resistive Load
• - Rated voltage / insulation: 690 V AC
• 600/690 V insulation
• - Rated making capacity: 110 A (AC Power Circuit)
• - Rated for continuous operation at these current levels under specified conditions
• - IP rating: IP2X
• - Mounting: Printed Circuit Boards
• - Dimensions: Width 45 mm, Height 58 mm, Depth 57 mm
• - Weight: 0.225 kg
• - Fuse rating: 25 A (gG at ≤440 V for power circuit
• 25 A aM for power circuit) -> fuse ratings are provided according to applicable standards and should be used as recommended
• - Standards: EN/IEC 60947-4-1, UL 60947-4-1, CSA, CE, etc. -> conforms to applicable safety and performance standards
• - Overvoltage category: CAT III
• - Operating time: 30-40 ms (coil energisation
• NO closing), 10 ms (coil de-energisation
• NO opening)
• - Range: TeSys
