IEC Magnetic Contactor, 1NO, 24V DC, 3 P, Screw Clamp MPN:LP4K1210BW3
Free Shipping
In Stock
This IEC Magnetic Contactor is a reliable and efficient solution for switching power circuits in various applications, including motor control and resistive-load applications. Its 24V DC coil and 3-pole design provide a high level of control and versatility. The unit's screw-clamp terminal and normally open auxiliary contact make it easy to integrate into existing systems. With a high making capacity and low impedance, this contactor is ideal for use in industrial settings, such as manufacturing, oil and gas, and renewable energy. Its compact design and durable construction ensure reliable operation in demanding environments.
Top product features:
- It has a normally open auxiliary contact for added functionality.
- It uses a screw-clamp terminal for secure and easy connection.
- It is designed for switching power circuits in motor control and resistive-load applications.
Top product applications:
- Motor control applications
- Resistive-load applications
- Power circuits switching
The item is an IEC Magnetic Contactor (3 poles) with a 24 V DC coil, intended for switching power circuits in motor control and resistive-load applications. It uses a screw-clamp terminal and offers one normally open auxiliary contact, with mounting options for plate or rail. The unit is part of the LP4K series and is rated for operation within the specified voltage ranges.
- Poles: 3
- - Coil voltage: 24 V DC
- - Auxiliary contact form: 1 NO
- - Terminal connection: Screw Clamp
- - Mounting: Plate, Rail
- - Rated voltage: 690 V AC
- - Full-load current (resistive): 20 A
- - Full-load current (inductive): 12 A
- - Making capacity: 110 A (AC Signalling), 144 A (AC Power)
- - Impedance: 3 mΩ
- - Impulse withstand voltage: 8 kV
- - Insulation resistance (signalling circuit): Greater Than 10 MΩ
- - Insulation voltage: 600/690 V
- - Fire rating: UL 94 V1
- NF F 16-101
- NF F 16-102
- - Overvoltage category: CAT III
- - Series: LP4K
- - Standards: EN/IEC 60947-4-1
- GB/T 14048.4
- UL 60947-4-1
- CSA C22.2 No 60947-4-1
- JIS C8201-4-1
- CB Scheme
- CCC
- UL
- CSA
- EAC
- CE
- UKCA
- - Mechanical durability: 30 Mcycles
- - Dimensions: Width 45 mm
- Height 58 mm
- Depth 57 mm
- - Net weight: 0.235 kg
- - Fuses: 25 A (Power Circuit)
- 10 A (Signalling Circuit)
- - Working height: 6561.68 ft
