IEC Magnetic Contactor, 1NO, 24V AC, 3 P, Reversing, Quick Connect MPN:LC2K12107B7

• The Schneider Electric IEC Magnetic Contactor is a three-pole reversing, 24 V AC coil device used to switch power circuits in motor control and resistive load applications. It is an electrically operated switching device that opens or closes contacts via an electromagnetic coil. The unit is designed for mounting on plate or rail and features a 1NO auxiliary contact, Quick Connect terminations, and an IP20 enclosure, suitable for standard IEC magnetic contactor installations in control systems.

  - Action: Reversing

• - Poles: 3
• - Coil Voltage: 24 V AC
• - Auxiliary Contact Form: 1NO
• - Electrical Connection / Terminal Type: Faston Terminals
• Quick Connect
• - Mounting: Plate, Rail
• - Dimensions (D × H × W): 57 mm × 58 mm × 90 mm
• - Net Weight: 0.39 kg
• - IP Rating: IP20
• - Series: LC2K
• - Rated Voltage: 690 V AC
• - Full Load Current: Resistive 20 A
• Inductive 12 A
• - Rated Making Capacity: 144 A @ 690 V (Power Circuit)
• 110 A (Signalling Circuit)
• - Impulse Withstand Voltage: 8 kV
• - Mechanical Durability: 5 Mcycles
• - Electrical Durability: 0.3 Mcycles (20 A, AC-1)
• 1.3 Mcycles (12 A, AC-3/AC-3e)
• - Fire Rating: UL 94 V1
• NF F 16-101
• NF F 16-102
• - Standards: EN/IEC 60947-4-1
• GB/T 14048.4
• UL 60947-4-1
• CSA C22.2 No 60947-4-1
• JIS C8201-4-1
• CB Scheme
• CCC
• UL
• CSA
• EAC
• CE
• UKCA
• - Hold VA: 4.5 VA
• - Inrush VA: 30 VA
• - Working Height: 6561.68 ft
• - Signalling Circuit Frequency: Less Than 400 Hz
• - Switching Current: 5 mA (Signalling Circuit)
