IEC Magnetic Contactor, 1NC, 110V AC, 3 P, Reversing, Screw Clamp MPN:LC2K1201F7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and versatile switching device ideal for motor control and resistive load applications. With a 110V AC coil and 1NC auxiliary contact, it provides efficient and precise control over electrical systems. Its reversing action and three-pole design make it suitable for various applications, including industrial automation and process control. The contactor's screw clamp terminals and IP20 enclosure ensure safe and secure connections. Rated for operation at up to 690V AC, it meets international standards and is suitable for use in a range of industries, including manufacturing, oil and gas, and power generation.
Top product features:
- The product has a reversing action, allowing for bidirectional control of a motor or resistive load.
- It is rated for operation at up to 690 V AC, providing a high level of electrical safety and compatibility with a wide range of applications.
- The product features screw clamp terminals, enabling secure and easy connections to wires and cables.
Top product applications:
- Motor Control
- Resistive Load
- Reversing Applications
The Schneider Electric IEC Magnetic Contactor is a three-pole, reversing-action switching device (LC2K series) rated for use in motor control and resistive load applications within specified parameters. Equipped with a 110 V AC coil, 1NC auxiliary contact, screw clamp terminals, and compatible mounting options. Conforms to IP20 enclosure standards
- fire ratings are based on applicable testing standards. Rated for operation at up to 690 V AC
- insulation voltage ratings are as specified, and is part of Schneider Electric’s LC2K family.
- Action: Reversing
- - Application: Motor Control, Resistive Load
- - Auxiliary Contact Form: 1NC
- - Coil Voltage: 110 V AC
- - Poles: 3
- - Electrical Connection: Screw Clamp Terminals
- - Mounting: Plate, Rail
- - IP Rating: IP20
- - Series: LC2K
- - Fire Rating: UL 94 V1
- NF F 16-101
- NF F 16-102
- - Net Weight: 0.39 kg
- - Rated Voltage: 690 V AC
- - Rated Insulation Volts: 600/690 V
- - Standards: EN/IEC 60947-4-1, GB/T 14048.4, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, CB Scheme, CCC, UL, CSA, EAC, CE, UKCA
- - Mechanical Durability: 5 Mcycles
- - Depth: 57 mm
- - Height: 58 mm
- - Width: 90 mm
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.80
