IEC Magnetic Contactor, 2NC/2NO, 500V AC, 4 P, Quick Connect MPN:LC1K090087S7
Free Shipping
In Stock
The IEC Magnetic Contactor from Schneider is a reliable and efficient power switching device designed for various applications. Suitable for use in 500V AC systems, this 4-pole contactor features 2NC/2NO auxiliary contacts and Quick Connect terminals for easy installation. Its compact form factor and lightweight design make it ideal for use in a range of industries, including manufacturing, automation, and power distribution. With its high performance and durable construction, this contactor ensures smooth and reliable operation, reducing downtime and increasing productivity. It's perfect for use in applications such as motor control, lighting systems, and HVAC systems.
Top product features:
- The IEC Magnetic Contactor has 2NC/2NO auxiliary contacts.
- It is designed for use with 500 V AC coils.
- It features Quick Connect terminals.
Top product applications:
- Industrial Control Systems
- Motor Control Circuits
- Automation Systems
The IEC Magnetic Contactor is a 4-pole power switching device from the LC1K series with 2NC/2NO auxiliary contacts. It is designed for use with 500 V AC coils
- suitable within the specified voltage ratings. The unit uses Quick Connect terminals and is compatible with standard mounting options (Plate, Rail). It has a compact form factor (58 mm high, 45 mm wide, 57 mm deep) and a net weight of 0.18 kg.
Key features:
- - Type/series: IEC Magnetic Contactor, LC1K, 4 poles with 2NC/2NO auxiliary contacts
- - Coil and voltage: Designed for use with 500 V AC coils
- suitable within the specified voltage ratings
- Overvoltage CAT III
- - Connections: Electrical connection Faston Terminals
- Terminal connection type Quick Connect
- - Mounting: compatible with standard mounting options (Plate, Rail)
- - Dimensions/weight: 58 mm H x 45 mm W x 57 mm D
- 0.18 kg
- - Electrical ratings: electrical ratings based on standardized testing conditions
- - Protection/standards: IP2X
- Fire rating UL 94 V1, NF F 16-101, NF F 16-102
- Standards EN/IEC 60947-4-1, UL 60947-4-1, CE, etc.
- - Electrical performance: Inrush 30 VA
- Watts Loss 1.3 W
- Hold VA 4.5 VA
- Impedance 3 mΩ
- withstands impulse voltages up to the specified value under test conditions
- - Environment/mechanical: Mercury Free, Toxic Heavy Metal Free
- Shock Resistance up to 10–15 G
- Vibration 4 G (Closed), 2 G (Open)
- Mechanical Durability 10 Mcycles
- - Other specs: Working Height 6561.68 ft
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.40
