IEC Magnetic Contactor, 1NC/1NO, 110V AC, 3 P, Reversing, Screw Clamp MPN:LC2D09F7

• The Schneider Electric IEC Magnetic Contactor is a 3-pole, reversing unit rated for operation within IEC-standard specifications. It operates with a 110 V AC coil and features a 1NC/1NO auxiliary contact configuration. The contactor is part of the LC2D series, compatible with specified mounting options and wiring methods. It is rated for use with motor control and resistive loads within specified parameters and equipped with a protective cover meeting applicable standards.

  - Action: Reversing

• - Poles: 3
• - Coil Voltage: 110 V AC
• - Auxiliary Contact Form: 1NC/1NO
• - Application: Motor Control, Resistive Load
• - Electrical Connection: Screw Clamp Terminals
• - Mounting: Plate, Rail
• - Series: LC2D
• - Includes Protective Cover: Yes
• - IP Rating: IP20
• - Rated Voltage: 690 V AC, 300 V DC
• - Rated Making Capacity: 250 A @ 440 V (Power Circuit)
• 140 A (AC Signalling)
• 250 A (DC Signalling)
• - Full Load Current: Inductive 9 A
• Resistive 25 A
• - Net Weight: 0.687 kg
• - Dimensions: Width 90 mm
• Height 77 mm
• Depth 86 mm
