IEC Magnetic Contactor, 1NO, 220V AC, 3 P, Screw Clamp MPN:LC1K1210M7

• The IEC Magnetic Contactor is a three-pole electrical switch (3 P) with a single normally open auxiliary contact (1NO) and a 220 V AC coil. It is part of the LC1K series and rated for use with motor control and resistive loads within specified parameters. The device uses an electromagnetic coil to open or close power contacts and is equipped with screw clamp terminals for wiring connections.

  Key features:

  • - Poles: 3
  • Auxiliary Contacts: 1 NO
  • - Coil Voltage: 220 V AC
  • - Electrical Connection: Screw Clamp Terminals
  • - Mounting: Plate, Rail
  • - Dimensions: Depth 57 mm, Height 58 mm, Width 45 mm
  • - Net Weight: 0.18 kg
  • - Rated for operation at voltages up to 690 V AC
  • insulation ratings conforming to standards
  • - Series: LC1K
  • Item: IEC Magnetic Contactor
  • - IP Rating: IP2X
  • - Full Load Current: up to 12 A (inductive) and 20 A (resistive) within specified conditions
  • - Rated Making Capacity: 110 A (AC Signalling), 144 A (AC Power) under standard test conditions
  • - Mechanical Durability: tested over specified cycles under normal operating conditions
  • - Electrical Durability: designed to withstand specified electrical switching cycles within standardized testing parameters
  • - Overvoltage Category: CAT III
  • - Impedance: 3 mΩ
  • - Impulse Withstand Voltage: 8 kV
  • - Hold VA: 4.5 VA
  • - Coil Hold Power: 4.5 VA
  • - Standards: EN/IEC 60947-4-1, UL 60947-4-1, CSA, CE, UKCA, etc. (listed standards)
  • - Rated Short-Time Withstand Current: range across load types (various values provided)
