IEC Magnetic Contactor, 1NC, 24V AC, 3 P, Screw Clamp MPN:LC1K1201B7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient motor control and resistive load device designed for a wide range of applications. With its 24V AC coil voltage and 3-pole configuration, it can handle currents up to 12A inductive and 20A resistive, making it suitable for use in various industries such as manufacturing, HVAC, and water treatment. Its compact design and screw clamp terminal connections provide easy installation and secure wiring. The contactor's high breaking and making capacities ensure reliable operation, while its fire-resistant rating and vibration resistance make it a safe choice for harsh environments.
Top product features:
- Operational control circuit voltage limits are between 0.8 to 1.15 Uc (at 50°C), while drop-out limits range from 0.2 to 0.75 Uc (at a temperature of about50°C).
- The rated breaking capacity ranges from70A @660to690Vto110A @440V.
- The product features three poles for electrical connection.
Top product applications:
- Motor control and resistive load device
- Resistive load device
- Motor control device
The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a motor control and resistive load device. It operates with a coil voltage of 24V AC, compatible with applications within the specified power range. This contactor has an auxiliary contact form of 1NC and features three poles for electrical connection. The product's specifications include handling currents up to 12A inductive and 20A resistive, with fuse amps at 25A for the power circuit and 10A for the signaling circuit.
Key Features:
- - Operational control circuit voltage limits are between 0.8 to 1.15 Uc (at 50°C), while drop-out limits range from 0.2 to 0.75 Uc (at a temperature of about50°C).
- - Fire rating complies with UL94 V1, NF F16-101, NF F16-102 standards.
- - Impedance stands at approximately3 mOhm.
- - Insulation resistance range exceeds10 MOhms on the signalling circuit.
- - Operating wattage varies depending on voltage levels
- may reach a maximum of approximately5.5 kW under certain conditions.
- - Operating speed clocks in at3600 cycles per hour.
- -The rated breaking capacity ranges from70A @660to690Vto110A @440V
- rated making capacity reaches144AfortheACpowercircuitand110AfortheACsignallingcircuit.
- -The terminal connection type is a screw clamp intended for use in securing wires or cables within its enclosure.
- -Vibration resistance measurements are4G when contact is closed and2G when open under testing conditions.
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 68 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.40
