IEC Magnetic Contactor, 1NC/1NO, 24V DC, 4 P, Non-Reversing, Screw Clamp MPN:LC1D128BD
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient device for controlling electrical circuits in various applications. With its 4-pole, non-reversing design and 24V DC coil, it provides precise control and minimizes energy losses. The 1NC/1NO auxiliary contact form ensures secure and reliable switching. Suitable for use in industrial automation, HVAC systems, and other applications where precise control is essential, this magnetic contactor offers a reliable and efficient solution for controlling electrical circuits. Its compact design and screw clamp terminals make it easy to integrate into existing systems.
Top product features:
- The Schneider Electric IEC Magnetic Contactor has a 1NC/1NO auxiliary contact form.
- It is a non-reversing device.
- It uses screw clamp terminals.
Top product applications:
- Control Panel Assembly
- Power Distribution Boards
- Machine Automation and Control Systems
The Schneider Electric IEC Magnetic Contactor is a 4-pole, non-reversing device with a 24 V DC coil and auxiliary contact form 1NC/1NO. It uses screw clamp terminals and is rated for operation within specified load types and conditions, with a protective cover included.
- Poles: 4
- Auxiliary contacts: 1NC/1NO
- Reversing: non-reversing
- - Coil voltage: 24 V DC
- - Terminals: Screw Clamp
- - Mounting: Plate, Rail
- - Series: LC1D
- Item: IEC Magnetic Contactor
- - Rated voltage: rated for use within specified voltage ranges (see product specifications)
- - Rated making capacity: 250 A @ 440 V (Power Circuit)
- 140 A (AC Signalling Circuit)
- 250 A (DC Signalling Circuit)
- - Full Load Amps: rated to handle specified current loads under standard conditions
- - Features: includes features as described
- performance may vary based on application
- - IP Rating: IP20
- - Dimensions: Height 85 mm
- Width 45 mm
- Depth 99 mm
- - Net Weight: 0.525 kg
- - Impulse withstand voltage: tested to withstand specified impulse voltages according to standards
- - Overvoltage Category: CAT III
- - Standards: CSA C22.2 No 14, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, IEC 60947-5-1, UL 508
- - Insulation Resistance: Greater Than 10 MOhms (Signalling Circuit)
- - Electrical durability: 0.8 Mcycles
- Mechanical durability: 30 Mcycles
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.24
