IEC Magnetic Contactor, 1NC/1NO, 24V DC, 4 P, Non-Reversing, Screw Clamp MPN:LC1D188BD
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor LC1D is a reliable and efficient solution for controlling power circuits in IEC-standard control systems. Its compact design and screw clamp terminals make it easy to install and integrate into various applications. Ideal for use in industrial automation, the contactor features a 24V DC coil and 1NC/1NO auxiliary contacts, ensuring safe and reliable switching. Suitable for use in a wide range of applications, including conveyor systems, pumps, and machinery control, the LC1D contactor provides fast and reliable switching, making it an essential component for industrial control systems.
Top product features:
- IEC Magnetic Contactor with 24V DC coil
- Four-pole, non-reversing switching device for controlling power circuits
- Mechanically linked 1 NO + 1 NC auxiliary contacts for added functionality
Top product applications:
- Motor control
- Machine control
- Control of pumps and fans
The Schneider Electric IEC Magnetic Contactor LC1D (TeSys Deca) is a four-pole, non-reversing, electrically operated switching device designed to control power circuits in IEC-standard control systems. It features a 24 V DC coil and 1NC/1NO auxiliary contacts (mechanically linked 1 NO + 1 NC). The contactor features screw clamp terminals and an enclosure designed according to standard specifications. It is rated for operation within the specified voltage ranges (up to 690 V) and conforms to relevant standards and is part of the LC1D series designed for standardized sizing and interchangeability.
- Coil voltage: 24 V DC
- - Poles and contacts: 4P
- 2 NO + 2 NC
- Auxiliary contacts: 1NC/1NO
- - Reversing capability: Non-Reversing
- - Terminals: Screw Clamp (control and power circuits)
- - Protection and enclosure: IP20 front face
- Protective cover: With
- - Mounting: Plate, Rail
- - Dimensions and weight: 45 mm wide
- 107 mm deep
- 91 mm high
- 0.585 kg
- - Environment and durability: Environmental ratings specify compliance with standard conditions, but do not guarantee performance under all environmental factors.
- - Electrical ratings: Electrical ratings specify maximum voltages within which the device can be operated safely when used as directed (Ue/Ui up to 690 V AC)
- - Current ratings and making capacity: Electrical ratings are based on standardized testing conditions and do not imply suitability beyond those parameters.
- - Short-time withstand: Short-time withstand values are provided based on specific test conditions, not guarantees of performance during actual use.
- - Fuses: 10 A (Signalling Circuit)
- 50 A (Type 1 Power Circuit)
- 35 A (Type 2 Power Circuit)
- - Time performance: Closing 53.55–72.45 ms
- Opening 16–24 ms
- - Standards: EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, IEC 60947-5-1, UL 60947-4-1, UL 60947-5-1, CSA C22.2 No 60947-4-1, CSA C22.2 No 60947-5-1, GB/T 14048.4, plus other listed approvals
- - Series and range: Series LC1D
- Range TeSys Deca
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.39
