IEC Magnetic Contactor, 1NC/1NO, 24V DC, 4 P, Non-Reversing, Screw Clamp MPN:LC1DT25BL
Free Shipping
In Stock
The Schneider IEC Magnetic Contactor is a reliable and efficient switching device suitable for controlling resistive loads in various applications. Its 4-pole design and 24V DC coil ensure precise control and high performance. The device includes 1NC/1NO auxiliary contacts and screw clamp terminals for easy connections. With a protective cover and IP20 enclosure, it provides a safe and durable solution. Ideal for use in industrial control systems, the IEC Magnetic Contactor offers benefits such as high reliability, low maintenance, and easy installation. Suitable for applications in electrical supplies, it is a versatile choice for a wide range of industries.
Top product features:
- 4-pole design allows for control of multiple circuits
- 1NC/1NO auxiliary contacts enable additional control and monitoring options
- Screw clamp terminals provide secure and easy electrical connections
Top product applications:
- Motor control
- Automated production lines
- Control of resistive loads
The IEC Magnetic Contactor (LC1D series) is a 4-pole, non-reversing, electrically operated switching device with a 24 V DC coil and is rated for controlling resistive loads within specified parameters and includes 1NC/1NO auxiliary contacts (2 total), screw clamp terminals, and a protective cover.
- Poles and auxiliary contacts: 4 poles
- 2 auxiliary contacts (1NC/1NO)
- non-reversing
- - Coil voltage: 24 V DC
- - Electrical connection: Screw clamp terminals
- - Mounting: Plate, Rail
- - Enclosure and cover: IP20
- Includes protective cover
- - Series/model: LC1D
- Item: IEC Magnetic Contactor
- - Rated voltage: up to 690 V AC / 300 V DC
- Full-load current: up to 25 A under specified conditions
- - Rated making capacity: Based on standard testing conditions
- actual performance may vary depending on application specifics
- - Durability: Durability ratings are based on standardized testing cycles under controlled conditions. Actual lifespan may vary with usage environment
- - Impulse withstand: Designed to withstand impulse voltages of up to specified test levels under laboratory conditions. Not indicative of operational voltage tolerance or safety margin during normal use
- - Non-overlap time: Non-overlap time specifications are provided as typical values based on testing
- actual timing may vary slightly during operation
- - Operating times: Typical operating times measured under test conditions
- actual response times can differ depending on system configuration and environmental factors
- - Fusing: Fuses rated for the specified currents but do not guarantee protection against all fault conditions or ensure safety during faults
- - Standards: CSA C22.2 No 14
- EN 60947-4-1
- EN 60947-5-1
- IEC 60947-4-1
- IEC 60947-5-1
- UL 508
- UL
- etc.
- - Temperature rating: Max. Temperature 850°C
- - Mechanical shock / vibration: 10 G (Open)
- 15 G (Closed)
- 4 G (Closed)
- 2 G (Open)
- - Environmental notes: Mercury Free, PVC Free, Toxic Heavy Metal Free, Pollution Degree 3
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.25
