IEC Magnetic Contactor, 1NC/1NO, 24V DC, 4 P, Non-Reversing, Screw Clamp MPN:LC1DT25BD
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for resistive load applications. Its compact design and screw clamp terminals make it easy to integrate into various systems. This device operates with a 24V DC coil voltage and features a non-reversing, 4-pole design for consistent performance. Suitable for use in industrial settings, it can handle loads up to 25A and withstands high impulse voltages. Its durable construction and compliance with international standards make it an ideal choice for applications requiring high reliability and safety. Use it in control panels, machines, and other equipment to ensure smooth operation and extend lifespan.
Top product features:
- Non-reversing operation allows for consistent and predictable control of electrical loads.
- Screw clamp terminals provide a secure and easy-to-use electrical connection.
- The product meets international standards for safety and performance, including CSA C22.2 No14, EN60947-4-1, and EN60947-5-1.
Top product applications:
- Resistive Load Applications
- Resistive load applications such as lighting, heating, and motor control systems
- Control systems for industrial equipment and machinery
The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a non-reversing, 4-pole device designed for resistive load applications. It operates with a coil voltage of 24V DC and has an auxiliary contact form of 1NC/1NO. The contactor features screw clamp terminals for electrical connection and can be mounted on either a plate or rail. With dimensions of 99mm in depth, 85mm in height, and 45mm in width, this compact unit includes a protective cover and weighs just 0.365 kg.
Key Features:
- - Full Load Amps: This device is rated for both inductive and resistive loads up to 25 A.
- - Durability: It has a specified electrical durability of 0.8 Mcycles (at less than 440 V) and mechanical durability of up to30 Mcycles.
- - Environmental Attributes: The product is mercury-free and PVC-free.
- - Fire Rating: Certified with UL94 V1 fire rating.
- - Impulse Withstand Voltage: Rated for impulse voltages up to6 kV.
- - Overvoltage Category: Classified under CAT III overvoltage category.
- - Rated Breaking Capacity & Making Capacity: Specified breaking capacity at250 A @440V
- making capacity ranges from140 A (AC Signalling Circuit),250 A (DC Signalling Circuit), to250 A @440V (Power Circuit).
- - Standards Compliance: Meets various international standards including CSA C22.2 No14, EN60947-4-1, EN60947-5-1 among others.
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.22
