IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Non-Reversing, Spring Type MPN:LC1D093BL
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for switching motor control and resistive load circuits. Its 3-pole, non-reversing design and 24V DC coil make it suitable for a wide range of applications, including motor control and resistive load circuits. With spring-type terminals and a protective cover, this contactor provides a secure and durable connection. Its high-rated making and breaking capacity, along with a low full load current, make it an ideal choice for demanding applications. Suitable for use in industrial settings, this contactor is a valuable addition to any electrical system.
Top product features:
- 3-pole design for switching motor control and resistive load circuits
- Non-reversing design for applications where motor direction is fixed
- Spring-type terminals for easy and secure electrical connections
Top product applications:
- Motor Control
- Resistive Load
- Non-reversing applications
The Schneider Electric IEC Magnetic Contactor is a 3-pole, non-reversing design with a 24 V DC coil and 1NC/1NO auxiliary contacts. It features spring-type terminals and is rated for use in switching motor control and resistive load circuits within specified parameters.
- Poles: 3
- - Coil voltage: 24 V DC
- - Auxiliary contacts: 1NC/1NO
- - Reversing capability: Non-reversing design
- suitable for non-reversing applications
- - Application: Motor Control, Resistive Load
- - Mounting: Plate, Rail
- - Electrical connection: Spring Terminals
- - Series: LC1D
- - IP rating: IP20
- - Rated voltage: 690V AC / 300V DC
- - Rated making capacity: 250 A @ 440 V (Power Circuit)
- 140 A (AC Signalling)
- 250 A (DC Signalling)
- - Rated breaking capacity: 250 A @ 440 V
- - Full load current: Resistive 20 A
- Inductive 9 A
- - Net weight: 0.48 kg
- - Dimensions: Width 45 mm
- Height 99 mm
- Depth 95 mm
- - Protective cover: Yes
- - Non-overlap time: 1.5 ms
- - Mechanical durability: 30 Mcycles
- - Maximum rated operating temperature: 850°C (if applicable)
- - Shock resistance ratings under specified test conditions
- - Mechanical operation rate based on standard testing conditions
- - Insulation voltage: 600/690 V
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.22
