IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Non-Reversing, Spring Type MPN:LC1D093BD
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for motor control and resistive load applications. Compatible with 24V DC and featuring a 1NC/1NO auxiliary contact form, this non-reversing contactor is ideal for use in single-phase and three-phase systems. With a high-rated breaking capacity of 250A @ 440V and a mechanical durability of 30 Mcycles, it can handle demanding applications with ease. Suitable for use in a range of industries, including manufacturing, HVAC, and water treatment, this contactor offers a reliable and efficient solution for controlling motors and loads.
Top product features:
- Non-reversing operation to prevent accidental motor rotation
- Integrated bi-directional peak limiting diode suppressor to protect against voltage spikes
- Spring terminals for easy electrical connection
Top product applications:
- Motor control
- Resistive load applications
- General purpose control
The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a non-reversing, spring type contactor intended for use in motor control and resistive load applications. It is compatible with a coil voltage of 24V DC and has an auxiliary contact form of 1NC/1NO. The product includes spring terminals intended for electrical connection and includes an integrated bi-directional peak limiting diode suppressor. Its environmental attributes include being mercury-free and PVC-free.
Key Features:
- - Depth: 95mm, Height: 99mm, Width: 45mm
- - Electrical Durability: Ranges from 0.6 Mcycles to 2 Mcycles depending on the conditions.
- - Fire Rating: UL94 V1
- - Full Load Amps - Inductive: 9A
- Resistive:20A
- - Fuse Amps range from10 A (Signalling Circuit) to25 A (Type Power Circuit)
- - Horsepower compatibility varies from Single Phase -240V AC at1 hp to Three Phase -480V AC at5 hp.
- - IP Rating :IP20
- - Operating wattage can vary under different conditions, within the range of 2.2 kW to 5.5 kW.
- -Mechanical Durability :30 Mcycles
- -Rated Breaking Capacity :250 A @440V
- -Reversing Capability :Non-Reversing
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.21
