IEC Magnetic Contactor, 1NC/1NO, 48V AC, 3 P, Screw Clamp MPN:LC1D50LE7

• The Schneider Electric IEC Magnetic Contactor LC1D (TeSys Deca) is a 3-pole, electrically operated switching device with a 48 V AC coil and a 1NC/1NO auxiliary contact. It is intended for use in IEC-standard control systems within specified parameters and rated for operation within specified load types and conditions. Wiring uses screw clamp terminals

• the unit can be mounted on a plate or a rail, and includes a protective cover (does not imply safety guarantee).

  Key features

• - Coil voltage: 48 V AC
• coil protection: without built-in bidirectional peak-limiting diode suppressor
• - Poles and contacts: 3 poles
• 3 NO main contacts
• auxiliary contact form: 1NC/1NO
• - Electrical ratings: rated voltage 690 V AC
• rated making capacity 900 A @ 440 V (Power Circuit)
• 140 A (AC Control Circuit)
• - Current ratings: full load current 50 A (inductive)
• 80 A (resistive)
• - Protection and enclosure: IP2X
• includes a protective cover (does not imply safety guarantee)
• fuse ratings are 10 A (Control Circuit) and 100 A (Power Circuit Type 1/2)
• - Mechanical and electrical endurance: 6,000,000 cycles
• specified non-overlap times under test conditions
• actual performance may vary depending on system configuration
• - Physical and installation: width 75 mm
• height 127 mm
• depth 119 mm
• weight 1.4 kg
• mounting: plate and rail
• - Standards and certifications: TeSys Deca range
• LC1D series
• conforms to these standards when used as directed
• does not guarantee compliance in all applications or environments
• - Additional ratings: impulse withstand voltage 8 kV
• shock and vibration ratings available (e.g., 15 G closed, 10 G open
• 4 G closed, 2 G open)
• - Environmentally conscious: PVC Free, Mercury Free, Toxic Heavy Metal Free
