IEC Magnetic Contactor, 1NC/1NO, 110V AC, 4 P, Non-Reversing, Screw Clamp MPN:LC1D258F7

• The item is an IEC Magnetic Contactor (TeSys Deca) with 4 poles and non-reversing operation. It uses a 110 V AC coil and screw clamp terminals, and includes two auxiliary contacts configured as 1NO/1NC (2 total). It is rated for switching power circuits within specified load types and conforms to IEC standards.

  Key features

• - Poles: 4
• - Coil voltage: 110 V AC
• - Auxiliary contacts: 2 total (1NO/1NC)
• - Reversing: Non-Reversing
• - Terminal type: Screw Clamp
• - Mounting: DIN Rail, Plate (Mounts on Plate, Rail)
• - Enclosure: No Enclosure
• IP20
• - Series/Frame: TeSys Deca
• - Maximum voltage rating: 690 V AC
• - Rated currents: 40 A resistive
• 25 A inductive
• - Rated making capacity: 140 A (AC Signalling), 250 A (DC Signalling), 450 A @ 440 V (Power Circuit)
• - Rated breaking capacity: 450 A @ 440 V
• - Frequency: 50/60 Hz
• - Impulse withstand voltage: 6 kV
• - Protective cover: Yes
• - Embedded surge suppressor: No
• - Insulation resistance: Greater than 10 MΩ (Signalling Circuit)
• - Standards: UL/CSA/IEC (example codes listed in the standards attribute)
• - Weight: 0.425 kg
• - Dimensions: Height 4.13 in
• Width 1.77 in
• Depth 3.9 in
• - Operating temperature range: -40°F to 140°F
