IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Non-Reversing, Spring Type MPN:LC1D183BL
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for motor control and resistive load applications. This non-reversing, spring type contactor operates with a coil voltage of 24V DC and features three poles, two auxiliary contacts, and a built-in bi-directional peak limiting diode suppressor. Suitable for single-phase (3 hp) to three-phase (5 hp to 15 hp) applications, it offers full load amps of 18 A inductive and 32 A resistive, with electrical durability rated up to 1.65 Mcycles. Ideal for use in various industries, including manufacturing, construction, and energy management, this contactor ensures safe and efficient operation.
Top product features:
- Non-reversing design prevents accidental motor start-up when power is applied in reverse polarity.
- Built-in bi-directional peak limiting diode suppressor protects against voltage spikes and electrical surges.
- Three poles allow for control of a single-phase motor or resistive load up to 15 horsepower.
Top product applications:
- Motor control applications
- Resistive load applications
- Non-reversing applications
The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a non-reversing, spring type contactor designed for motor control and resistive load applications. It operates with a coil voltage of 24V DC and has an auxiliary contact form of 1NC/1NO. This product comes with a built-in bi-directional peak limiting diode suppressor and includes protective cover. The device features three poles, two auxiliary contacts, and can be mounted on either plate or rail.
Key Features:
- - Full Load Amps: Inductive at 18 A
- Resistive at 32 A.
- - Electrical Durability: Rated for operation up to 1.65 Mcycles under specified conditions.
- - Horsepower Compatibility: Varies from single phase (3 hp) to three-phase (5 hp to 15 hp).
- - Environmental Attributes: Free from mercury, PVC, toxic heavy metals
- Pollution Degree is rated as 3.
- - Operating Speed & Time: Operates at the speed of 3600 cycles per hour with varying operating times for closing/opening actions.
- - Mechanical Durability: Rated for mechanical durability of up to 30 Mcycles.
- - Rated Voltage & Insulation Volts: Rated voltage stands at both AC (690V) and DC (300V), while insulation volts are rated between 600/690V.
- - Standards Compliance: Complies with multiple international standards including CSA C22.2 No14, EN60947 series, UL508 among others.
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.37
