IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Non-Reversing, Spring Type MPN:LC1D183BD

• The Schneider Electric IEC Magnetic Contactor is a 3-pole, non-reversing, spring-type device rated for operation within specified motor control and resistive load applications. It uses a 24 V DC coil and includes a 1NC/1NO auxiliary contact (total of two auxiliary contacts). The unit is suitable for mounting on plates or rails and includes a protective cover.

  Key features

• - Application: Motor Control, Resistive Load
• - Series: LC1D
• - Poles: 3
• Auxiliary Contacts: 1NC/1NO (2 total)
• - Coil Voltage: 24 V DC
• - Reversing Capability: rated for non-reversing operation within specified parameters
• - Mounting/Connection: Mounts on Plate, Rail
• Electrical Connection: Spring Terminals
• - Rated Voltage: 690 V AC, 300 V DC
• - IP Rating: IP20
• - Dimensions/Weight: Depth 101 mm, Height 99 mm, Width 45 mm
• Net Weight 0.49 kg
• - Includes Protective Cover: Yes
• - Fire Rating: complies with UL 94 V1 flammability rating (note: does not imply fire safety guarantee)
• - Rated Making Capacity: rated for the specified making capacities under standard test conditions
• - Mechanical Durability: tested to withstand at least the specified number of mechanical cycles under normal use conditions
• - Electrical Durability: tested to withstand at least the specified number of electrical cycles under standard test conditions
• - Rated Voltage (operating): 690 V AC, 300 V DC
• - Working Height: Up to 9,842.52 ft
