IEC Magnetic Contactor, 1NC/1NO, 110V AC, 4 P, Non-Reversing, Screw Clamp MPN:LC1D128F7

• The SCHNEIDER ELECTRIC - IEC Magnetic Contactor is a non-reversing, 4-pole contactor intended for use with resistive load applications. It operates with a coil voltage of 110V AC and features an auxiliary contact form of 1NC/1NO. The contactor has screw clamp terminals for both power and control circuits, accommodating various cable stiffness types. With an average impedance of 2.5 mOhm, it meets the requirements of IACS E10 and IEC 60947-1 Annex Q category D standards for damp heat exposure.

  Key Features:

• - Associated Fuse Rating: Offers different fuse ratings for signaling circuit (10 A gG) and power circuit (40 A gG at ≤690 V coordination type 1
• 25 A gG at ≤690 V coordination type 2).
• - Auxiliary Contacts Type: Mechanically linked contacts (1 NO + 1 NC) conforming to IEC standards.
• - Electrical Durability: Has been tested to handle approximately .8 million cycles under specified conditions.
• - Full Load Amps: Rated for inductive loads up to12 A and resistive loads up to25 A.
• - Protective Cover: Includes a protective cover. Always follow safety guidelines when using this product.
• - Rated Insulation Voltage: Power circuit rated at up to 690 V according to IEC standards
• Signaling circuit also rated at up to 690 V as per the same standard.
• - Operating Altitude: Designed for operation from sea level up to altitudes of about9842.52 ft or3000 m, performance may vary based on environmental factors.
• - Product Certifications: Holds certifications from various international bodies including RINA, GL, BV, UL, CSA among others
• always ensure local regulations are met before installation/use.
