IEC Magnetic Contactor, 1NC/1NO, 120V AC, 4 P, Screw Clamp MPN:LC1DT60AG7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for controlling and protecting electrical circuits. Suitable for a wide range of applications, including industrial, commercial, and residential use, this contactor provides four normally open contacts and one NC/NO auxiliary contact pair. Its 120V AC coil voltage and 4P configuration make it ideal for resistive load applications. With features such as screw clamp terminals, EverLink BTR screw connectors, and a protective cover, this contactor ensures safe and reliable operation. Its compact design and durable construction make it a great choice for applications where space and reliability are crucial.
Top product features:
- Has 4 normally open (4 NO) contacts for controlling multiple circuits
- Includes a protective cover for safe operation and reduced risk of electrical shock
- Can withstand high impulse and short-time withstand currents for reliable performance in demanding applications
Top product applications:
- Resistive load applications
- General control of resistive loads in various industrial and commercial settings
- Automated control of lighting systems
The Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 120V AC, 4P, Screw Clamp, is rated for operation within IEC system specifications. It includes four normally open (4 NO) contacts and one NC/NO auxiliary contact pair, rated according to specified standards. Coil voltage: 120 V AC as specified
- Control circuit connections: screw clamp terminals
- Power circuit connections: EverLink BTR screw connectors. This unit is part of the TeSys Deca LC1D range and includes a protective cover, with mounting options for plate or rail, suitable for resistive load applications within specified ratings.
Key features
- - Coil voltage: 120 V AC as specified
- - Poles / main contacts: 4P
- 4 NO
- - Auxiliary contacts: 1NC/1NO (one NC/NO auxiliary contact pair)
- - Control circuit connections: screw clamp terminals
- Power circuit connections: EverLink BTR screw connectors
- - Mounting and enclosure: Plate or Rail mounting
- protective cover included
- IP20 front face
- - Series/Range: LC1D
- TeSys Deca
- - Rated operational current (power circuit): 60 A AC-1 at ≤ 440 V
- - Rated making capacity: 140 A (AC signalling)
- 250 A (DC signalling)
- 800 A @ 440 V (power circuit)
- - Rated insulation voltage: Power circuit 600 V (UL/CSA)
- Signalling circuit 690 V (IEC 60947-1)
- - Impulse/short-time withstand: 6 kV impulse
- short-time withstand up to 320 A (10 s) and 720 A (1 s) for power circuit
- - Overvoltage category: CAT III
- - Environmental: Pollution Degree 3
- Mercury Free
- PVC Free
- Toxic Heavy Metal Free
- - Mechanical/durability: 6 Mcycles (mechanical)
- 4–5 W heat dissipation
- - Dimensions and weight: 120 mm depth
- 122 mm height
- 70 mm width
- 1.09 kg
- - Certifications: UL
- CSA
- CCC
- DNV
- LROS
- RINA
- GOST
- GL
- BV
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 2.40
