IEC Magnetic Contactor, No Auxiliary Contacts, 24V DC, 3 P, Non-Reversing, Screw Clamp MPN:LP4K0610BW3
Free Shipping
In Stock
The Schneider TeSys K IEC Magnetic Contactor is a reliable and efficient motor control solution for a wide range of applications. With a 24V DC coil and 3-pole non-reversing operation, it provides precise control over motor operations. Its screw clamp terminals ensure secure and easy connections. Suitable for use in industrial environments, this contactor is ideal for applications such as conveyor systems, pumps, and fans. Its robust design and high-quality components ensure reliable performance and long lifespan. The TeSys K contactor is a valuable addition to any industrial control system, providing efficient and safe motor control.
Top product features:
- The device has a non-reversing operation, ensuring that the motor will only operate in one direction.
- The device has a 24V DC coil, allowing for efficient and reliable operation in a wide range of applications.
- The device has embedded surge suppressor protection, safeguarding against voltage spikes and electrical surges.
Top product applications:
- Motor Control Panels
- Industrial Automation Systems
- Electrical Power Distribution Systems
The item is an IEC Magnetic Contactor used for motor control. It is a 3-pole device with a 24 V DC coil, non-reversing operation, and screw clamp terminals. It carries Schneider Electric’s TeSys K designation and uses IEC design standards for this type of device
- it does not include auxiliary contacts.
Key features
- - Coil voltage: 24 V DC
- - Poles: 3
- Reversing: Non-Reversing
- - Auxiliary contacts: Does not include auxiliary contacts
- - Terminal connection: Screw Clamp
- - Embedded surge suppressor: Yes
- - Enclosure: No Enclosure
- - Mounting style: DIN Rail, Plate
- Mounts On: Plate, Rail
- - Maximum voltage rating / Rated voltage: 690 V AC
- - Rated making capacity: 110 A
- - Rated breaking capacity: 110 A @ 415V, 440V, 220–230V, 380–400V
- 80 A @ 500V
- 70 A @ 660–690V
- - Frequency: 50/60 Hz
- - Full Load Amps (Inductive): 6 A
- - Impedance: 3 mΩ
- - Impulse withstand voltage: 8 kV
- - Fire rating: Complies with the specified fire safety standards listed
- - Standards: Certified to applicable standards including CSA, UKCA, and UL where indicated
- - Frame/Series/Code: TeSys K
- - Overvoltage category: CAT III
- - Dimensions (HxWxD): 2.28 in x 1.77 in x 2.24 in
- - Net weight: 0.235 kg
- - Operating speed: Rated for operation at a maximum of approximately 3600 cycles per hour under standard conditions
- - Temperature range: Max 122°F, Min -13°F
- - Rated insulation voltage: 600/690 V
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.49
