IEC Magnetic Contactor, 1NO, 120V AC, 3 P, Reversing, Screw Clamp MPN:LC2K1210G7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor LC2K is a versatile and reliable control device designed for use in industrial control panels. Its 3-pole, reversing action design and 1NO auxiliary contact make it ideal for applications requiring high switching capacity and flexibility. With a compact design and screw clamp terminals, it can be easily integrated into a variety of systems. The LC2K can handle a range of load types and conditions, making it suitable for use in applications such as motor control, lighting systems, and HVAC systems, providing reliable and efficient control and reducing downtime and maintenance costs.
Top product features:
- Three-pole, reversing action device
- Electromagnetically operated switch with 1NO auxiliary contact
- Compact design for connection via screw clamp terminals
Top product applications:
- Motor Control Circuits
- Industrial Lighting Systems
- Power Distribution Panels
The Schneider Electric IEC Magnetic Contactor LC2K is a three-pole, reversing action device with a 1NO auxiliary contact and a 120 V AC coil. It is a compact, electromagnetically operated switch rated for operation within specified load types and conditions. Designed for connection via screw clamp terminals
- compatible with standard mounting options in industrial control panels.
Key features
- - Series/Item: LC2K
- Type: IEC Magnetic Contactor
- Poles: 3
- Action: Reversing
- Auxiliary contact: 1NO
- - Coil voltage: 120 V AC
- Control circuit voltage range: 0.8–1.15 times the coil voltage
- Drop-out voltage range: 0.2–0.75 times the coil voltage at 50°C
- - Rated voltage: 690 V AC
- Electrical connections: Screw Clamp Terminals
- Mounting: Plate, Rail
- IP rating: IP20
- - Weight and dimensions: Net weight 0.39 kg
- Width 90 mm
- Height 58 mm
- Depth 57 mm
- - Electrical ratings: Full Load—Inductive 12 A
- Resistive 20 A
- Making capacity 144 A @ 690 V (Power), 110 A (Signalling) → electrical ratings are based on standardized testing conditions within specified parameters
- - Fusing: 25 A (Power Circuit), 10 A (Signalling Circuit) → fuse ratings are provided according to applicable standards and should be selected based on actual application requirements
- - Short-time withstand currents: 115 A (Power, 1 s)
- 105 A (Power, 5 s)
- 100 A (Power, 10 s)
- 80–110 A (Signalling, various durations) → short-time withstand current values are based on standardized testing procedures and do not imply continuous capability
- - Insulation/ratings: Rated insulation voltage 600/690 V
- Impulse withstand voltage 8 kV
- Mechanical durability 5 Mcycles → insulation ratings specify tested maximum voltages under controlled test conditions
- mechanical durability indicates expected operational cycles without guarantee of performance over time
- - Standards: EN/IEC 60947-4-1, GB/T 14048.4, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, CB Scheme, CCC, UL, CSA, EAC, CE, UKCA, TC IEC 60068, TC DIN 50016 → conforms to recognized standards but does not guarantee specific performance outcomes beyond compliance with these standards
- - Other: Reversing capability, 5 Mcycles mechanical durability, 4–top operational considerations such as switching and making capacity for both power and signalling circuits
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.81
