IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Reversing, Screw Clamp MPN:LC2D09BL

• The Schneider Electric IEC Magnetic Contactor is a 3-pole reversing contactor with a 24 V DC coil. It features 1NC/1NO auxiliary contacts and screw clamp terminals, and comes preassembled with a reversing power busbar. Labeled for TeSys D and TeSys Deca (LC2D) series, it is rated for operation within the specified voltage ranges.

  - Action: Reversing

• - Poles: 3P
• - Coil Voltage: 24 V DC
• - Auxiliary Contacts: 1NC/1NO (Mechanically linked 1 NO + 1 NC)
• - Power/Control Terminals: Screw Clamp
• - Device Presentation: Preassembled with reversing power busbar
• - Range/Series: TeSys
• TeSys Deca (LC2D)
• - Product Names: TeSys D
• TeSys Deca
• - Utilisation Category: AC-3
• AC-1
• AC-3e
• - Rated Operational Current: 9 A (AC-3, <60°C) power circuit
• 25 A (AC-1, <60°C) power circuit
• - Rated Voltage: Power circuit ≤ 690 V AC
• Power circuit ≤ 300 V DC
• - IP Rating: IP20
• - Mechanical Durability: 30 Mcycles
• - Connection Type: Screw Clamp Terminals
• - Mounting: Rail
• Plate
• - Net Weight: 1.017 kg
• - Dimensions: Width 90 mm
• Height 77 mm
• Depth 95 mm
• - Certifications: DNV
• CSA
• CCC
• UL
• GL
• LROS
• BV
• RINA
• GOST
• UKCA
