IEC Magnetic Contactor, 1NC/1NO, 110V AC, 3 P, Reversing, Screw Clamp MPN:LC2D25F7

• The Schneider Electric IEC Magnetic Contactor is a 3-pole, reversing type device from the TeSys Deca series. It operates from a 110 V AC coil and provides a 2-contact auxiliary arrangement (1NO/1NC) in addition to three normally open main contacts. The unit uses screw clamp terminals, supports DIN Rail or Plate mounting, and includes a protective cover. It is intended for use with motor control and resistive loads within specified ratings, rated for operation within the specified voltage ranges (690 V AC, 300 V DC), and is provided without an embedded surge suppressor or enclosure.

  - Action: Reversing

• - Poles: 3
• - Series / Contactor Style: TeSys Deca / IEC
• - Coil Voltage: 110 V AC
• - Auxiliary Contacts: 2 total (1NO/1NC)
• - Main Contacts: 3 normally open
• - Electrical Connection: Screw Clamp Terminals
• - Enclosure: No Enclosure
• - Protective Cover: Included
• - IP Rating: IP20
• - Mounting: DIN Rail, Plate
• - Frequency: 50/60 Hz
• - Rated Voltage: 690 V AC, 300 V DC
• - Rated Insulation Volts: 600/690 V
• - Max Operating Temperature: 140 °F (60 °C) as per specifications
• - Max Temperature Rating: 850 °C according to manufacturer data
• - Rated Making Capacity: as specified by manufacturer standards and testing conditions
• - Short-Time Withstand Current: short-time withstand current ratings based on standardized testing parameters
• - Full Load Amps (Inductive/Resistive): full load current ratings under standard test conditions
• - Hold / Inrush VA: power consumption during hold and inrush conditions within tested parameters
• - Impedance: 2 mΩ
• - Impulse Withstand Voltage: impulse withstand voltage as per applicable standards
• actual performance may vary depending on installation conditions
• - Shock Resistance: shock resistance measured under specific test methods
• actual resistance may vary in real-world applications
• - Vibration Resistance: vibration resistance levels based on standardized tests
• real-world durability may differ depending on environment
• - Standards: BV, CCC, CSA, CSA C22.2 No 14, DNV, EN 60947-4-1, EN 60947-5-1, GL, GOST, IEC 60335-1, IEC 60947-4-1, IEC 60947-5-1, LROS, RINA, UKCA, UL 508, UL Listed
• - Reversing: Yes
• - Signalling Frequency: 25 to 400 Hz
• - Protective Features: No Embedded Surge Suppressor
• - Fire Rating: UL 94 V1
• - Frame / Series: TeSys
• - Maximum Voltage Rating: 690 V AC
• - Operating Time (Closing / Opening): 12–22 ms (Closing), 4–19 ms (Opening)
• - Net Weight: 0.787 kg
• - Dimensions (W x H x D): 3.54 in x 3.35 in x 3.62 in
