IEC Magnetic Contactor, 1NC/1NO, 24V AC, 3 P, Reversing, Screw Clamp MPN:LC2D12B7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a versatile 3-pole reversing control device suitable for motor control and resistive loads. Its 24V AC coil and 1NC/1NO auxiliary contact provide reliable switching and control. The contactor is designed for use in a variety of applications, including industrial automation and HVAC systems. Its compact design and screw clamp terminals make it easy to install and maintain. With a high mechanical durability of 15 Mcycles and electrical operating durability of 2 Mcycles, this contactor is built to last. It's ideal for use in harsh environments and meets IP20 protection standards.
Top product features:
- Reversing action allows for bidirectional control of motors and loads
- 1NC/1NO auxiliary contact provides additional control and monitoring capabilities
- Screw clamp terminals enable quick and secure electrical connections
Top product applications:
- Motor Control
- Resistive Load
- Reversing
Schneider Electric IEC Magnetic Contactor is a 3-pole reversing control device with a 24V AC coil (coil voltage) and a 1NC/1NO auxiliary contact. It is designed for motor control and resistive loads, part of the TeSys series, and uses screw clamp terminals. It is rated for operation within the specified voltage ranges, and mounts on plate or DIN rail and includes a protective cover. Dimensions are 86 mm depth, 77 mm height, and 90 mm width, with a net weight of 0.697 kg.
- Action: Reversing
- - Application: Motor Control, Resistive Load
- - Auxiliary Contact Form: 1NC/1NO
- - Coil Voltage: 24V AC
- - Contactor Style: IEC
- Series: TeSys
- - Electrical Connection: Screw Clamp Terminals
- - Poles/Main Contacts: 3 poles
- 3 normally open main contacts
- - Includes Auxiliary Contacts: Yes
- - Includes Protective Cover: Yes
- - Rated Voltage: 690V AC, 300V DC
- - IP Rating: IP20
- - Mounting: Plate, DIN Rail
- Mounts On: Plate, Rail
- - Net Weight: 0.697 kg
- - Features: Without Built-In Suppressor Module
- - Fire Rating: UL 94 V1
- - Mechanical Durability: 15 Mcycles
- - Electrical Operating Durability: 2 Mcycles
Additional Information
- Country of Origin: ID
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 6 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.80
