IEC Magnetic Contactor, No Auxiliary Contacts, 110V AC, 4 P, Non-Reversing, Screw Clamp MPN:LC1K09008F7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for switching power circuits in industrial control panels. Rated for use with resistive and compatible load types, this 4-pole, non-reversing device offers a high level of performance and versatility. With a 110V AC coil and screw clamp terminals, it provides easy installation and maintenance. Suitable for applications in various industries, including electrical supplies, this contactor ensures safe and reliable operation, making it an ideal choice for use in control panels with high current requirements. Its compact design and durable construction also make it perfect for space-constrained environments.
Top product features:
- The Schneider Electric IEC Magnetic Contactor has a 2 NO + 2 NC main contact configuration.
- The device is rated for operation up to 690 V AC.
- The contactor has a maximum short-time withstand current of up to 90 A (1 s), 85 A (5 s), 80 A (10 s), 60 A (30 s), 45 A (1 min), 40 A (3 min), 20 A (15 min) for power circuit.
Top product applications:
- Motor control circuits
- HVAC control systems
- Power distribution units
The Schneider Electric IEC Magnetic Contactor is a 4-pole, non-reversing device with a 110 V AC coil and screw clamp terminals. It is an IEC-style magnetic contactor (TeSys series) rated for switching power circuits within specified parameters. It has no auxiliary contacts and is listed under IEC Magnetic Contactors. This item is rated for use in IEC control panels with resistive and compatible load types within its specified ratings.
- Coil voltage: 110 V AC
- - Poles: 4P
- Main contact configuration: 2 NO + 2 NC
- - Reversing: Non-Reversing
- - Auxiliary contacts: No
- - Electrical connections: Screw clamp terminals
- - Series/Frame: TeSys
- - Utilisation category: AC-1
- - Maximum voltage rating: Rated for operation up to 690 V AC
- Insulation voltage as per specifications
- - Rated making capacity / Rated operational current: rated according to the specified current capacities under defined conditions
- - IP rating: IP22
- Embedded surge suppressor: No
- - Enclosure: No Enclosure -> open device without enclosure, as specified
- - Ambient storage temperature: -50 to 80°C
- - Operating altitude: Suitable for operation at altitudes up to 2000 meters within environmental limits
- - Dimensions: Height 2.28 in
- Width 1.77 in
- Depth 2.24 in
- - Weight: 0.18 kg
- - Mounting: DIN Rail, Plate (Mounting Support: Rail
- Plate)
- - Impedance: 3 mΩ
- - Inrush VA: 30 VA
- Hold-in power: 4.5 VA
- Watts loss: 1.3 W
- - Impulse withstand voltage: Tested for impulse withstand voltage of up to 8 kV in accordance with standards
- - Short-time withstand current: up to 90 A (1 s), 85 A (5 s), 80 A (10 s), 60 A (30 s), 45 A (1 min), 40 A (3 min), 20 A (15 min) for power circuit
- - Operating speed: 3600 cycles per hour
- - Overvoltage category: CAT III
- - Vibration/shock: 4 G (Closed), 2 G (Open)
- Shock: up to 15 G (various axes)
- - Certifications: CB Scheme
- CCC
- UL
- CSA
- EAC
- CE
- UKCA
- - Rated making/short-time ratings and standards reflect IEC 60947-4-1/60947-5-1 scope and related tests.
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 1.90
- Package Height: 2.60
- Package Weight: 0.40
