IEC Magnetic Contactor, No Auxiliary Contacts, 120V AC, 4 P, Non-Reversing, Screw Clamp MPN:LC1D128G7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for power circuit switching in industrial applications. Suitable for resistive loads, this 4-pole non-reversing contactor offers screw clamp terminals and DIN Rail or Plate mounting options. With a compact design and low weight, it's easy to integrate into your system. The contactor is rated for 25A continuous current and 12A inductive current, making it ideal for a wide range of applications, including motor control, lighting, and HVAC systems. Its high-quality construction and compliance with international standards ensure safe and reliable operation.
Top product features:
- The Schneider Electric IEC Magnetic Contactor is a 4-pole, non-reversing, coil-operated switch that facilitates power circuit switching in accordance with applicable standards.
- It uses screw clamp terminals for secure and easy connections.
- The unit includes a protective cover for added safety and durability.
Top product applications:
- Resistive Load
- Industrial Automation
- Power Circuit Switching
The Schneider Electric IEC Magnetic Contactor is a 4-pole, non-reversing, coil-operated switch rated for operation with resistive loads within specified parameters. It uses screw clamp terminals and is compatible with DIN Rail or Plate mounting. The unit is part of the TeSys Deca family and is intended to facilitate power circuit switching in accordance with applicable standards.
- Coil voltage: 120 V AC
- - Poles/contacts: 4 poles
- main contacts 2 NO + 2 NC
- auxiliary contacts: No Auxiliary Contacts
- - Reversing: Non-Reversing
- - Mounting/terminals: DIN Rail, Plate
- Screw Clamp terminals
- - Load/application: Resistive Load
- - Maximum voltage (power circuit): 690 V AC
- - Full-load currents: Rated for maximum continuous current of 25 A (resistive) and 12 A (inductive) under specified conditions
- - Frequency: 50/60 Hz
- - IP/ enclosure: IP20 front face
- No Enclosure
- - Protective cover: Includes a protective cover as part of the product features
- - Dimensions/weight: Width 1.77 in
- Height 3.35 in
- Depth 3.62 in
- Weight 0.365 kg
- - Standards: EN 60947-4-1
- EN 60947-5-1
- UL 508
- UL Listed
- CSA
- IEC 60947-1
- - Series/frame: TeSys Deca
- - Other notable specs: Inrush 70 VA
- Hold-in 7.5 VA (60 Hz) / 7 VA (50 Hz)
- Impedance 2.5 mΩ
- Operating times 12–22 ms (closing), 4–19 ms (opening)
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.70
- Package Width: 3.80
- Package Height: 2.20
- Package Weight: 0.90
