IEC Magnetic Contactor, No Auxiliary Contacts, 110V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K1210F7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for controlling electrical loads in a variety of applications. Suitable for use in industrial and commercial settings, this 3-pole contactor features a non-reversing design and is rated for operation up to 690 V AC. With its compact size and screw clamp terminals, it is easy to integrate into existing systems. The contactor's high inrush and hold VA ratings ensure smooth and stable operation, making it ideal for use in applications such as motor control, lighting, and HVAC systems. Its durable design and IP22 rating provide long-lasting performance in harsh environments.
Top product features:
- The Schneider Electric IEC Magnetic Contactor is a 3-pole, non-reversing, electrically operated switch rated for operation within the specified parameters.
- It has three main normally open contacts.
- It supports mounting on DIN rails or plates.
Top product applications:
- Industrial Control Panel
- Automation and Control Systems
- High-Reliability Power Distribution
The Schneider Electric IEC Magnetic Contactor is a 3-pole, non-reversing, electrically operated switch rated for operation within the specified parameters. It uses a 110 V AC coil and is part of the TeSys K family. The device features screw clamp terminals and supports mounting on DIN rails or plates. It has three main normally open contacts and is intended for use with compatible load types as specified. The contactor is rated for operation up to 690 V AC
- enclosure options are available separately.
- Coil voltage: 110 V AC
- - Poles / main contacts: 3P, 3 NO
- - Reversing: Non-Reversing
- - Terminals / mounting: Screw Clamp Terminals
- Mounting: DIN Rail, Plate
- - Max voltage: 690 V AC
- - Full load amps: 20 A resistive, 12 A inductive
- - Frequency: 50/60 Hz
- - Series: TeSys K
- - Enclosure / IP rating: No Enclosure
- IP22
- - Impulse withstand: 8 kV
- - Inrush / Hold VA: 30 VA (inrush), 4.5 VA (holding)
- - Dimensions / weight: 1.77 in wide
- 2.28 in high
- 2.24 in deep
- 0.18 kg
- - Operating cycles: 3600 cyc/h
- - Certifications: CB Scheme
- CCC
- UL
- CSA
- EAC
- CE
- UKCA
