IEC Miniature Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0910B7

• Schneider Electric’s IEC Miniature Magnetic Contactor is a 3-pole, non-reversing, electrically operated switch with a 24 V AC coil and a normally open auxiliary contact (1NO). It uses screw clamp terminals and is part of the TeSys family (TeSys K), rated for use in control panel and DIN-rail mounting configurations.

  Key features:

  • - Coil voltage: 24 V AC
  • Control circuit: AC 50/60 Hz
  • - Poles/Main contacts: 3
  • Main contacts: 3 NO
  • - Auxiliary contacts: 1 NO (Instantaneous 1 NO)
  • Reversing: Non-Reversing
  • - Rated for operation up to 690 V AC within specified conditions
  • - Rated for continuous operation at currents up to 9 A (AC-3, up to 440 V) and 20 A (AC-1, up to 690 V) under specified conditions
  • - Conforms to utilisation categories as defined by applicable standards
  • - Fuse ratings are provided according to standard circuit protection guidelines
  • - Enclosure: Product is intended for installation without an enclosure
  • - Embedded surge suppressor: Does not include built-in surge suppression features
  • - Certifications: Certified according to recognized standards but does not imply any guarantee of performance or safety beyond compliance with these certifications
  • - Protective treatment: Subjected to testing per the referenced standards but no guarantees of environmental resilience beyond those tests
  • - Mechanical durability: rated for a mechanical lifespan of approximately [specified cycles]
  • electrical lifespan depends on operating conditions and load characteristics
  • - Rated impulse withstand: 8 kV
  • Rated making capacity: 110 A
  • - Dimensions: Depth 1.97 in
  • Height 1.73 in
  • Width 1.73 in
  • - Operating altitude: 2000 m (6561.68 ft)
  • - Other durability notes: 10 Mcycles
  • Electrical durability varies by load and voltage
