IEC Magnetic Contactor, 1NC/1NO, 200V-500V AC/DC, 4 P, Spring Type MPN:LC1G1504LSEA
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a versatile and reliable switching device suitable for a wide range of single-phase applications, including industrial control systems, HVAC, and lighting control. Its robust design and high-quality components ensure long-lasting performance and durability, with a mechanical operating durability of 8,000,000 cycles. The contactor's compact size and spring-type terminal connections make it easy to integrate into existing systems, while its IP20 ingress protection rating provides reliable operation in harsh environments. With a maximum voltage rating of 1000 V AC and a wide operating temperature range, this contactor is an ideal choice for demanding applications.
Top product features:
- The Schneider Electric IEC Magnetic Contactor has a coil-operated switching device rated for operation within the specified IEC standards.
- It includes two auxiliary contacts configured as 1NC/1NO.
- It supports plate mounting as per product design.
Top product applications:
- Industrial Control Panels
- Motor Control Centers
- Starters and Relays
The Schneider Electric IEC Magnetic Contactor is a four-pole, coil-operated switching device rated for operation within the specified IEC standards. It is rated for operation within the specified voltage range and compatible with spring-type terminal connections. The unit includes two auxiliary contacts configured as 1NC/1NO, is part of the TeSys Giga series, has a maximum voltage rating of 1000 V AC and an IP20 ingress protection rating. It is intended for single-phase applications within its specifications, does not include an integrated surge suppression device, and supports plate mounting as per product design
- durability depends on application conditions.
- Item: IEC Magnetic Contactor (Schneider Electric)
- - Series: TeSys Giga
- - Poles: 4
- - Phase: Single
- - Coil Voltage: 200–500 V AC/DC
- - Auxiliary Contacts: 2 total (1NC/1NO)
- - Includes Auxiliary Contacts: Yes
- - Terminal Connection Type: Spring Type
- - Maximum Voltage Rating: 1000 V AC
- - Frequency: 50/60 Hz
- - IP Rating: IP20
- - Integrated Surge Suppressor: No
- - Full Load Amps - Inductive: 230 A
- - Full Load Current - Inductive: 150 A
- - Full Load Amps - Resistive: 275 A
- - Full Load Current - Resistive: 275 A
- - Maximum Operating Temperature: 140 °F
- - Minimum Operating Temperature: -13 °F
- - Mechanical Operating Durability: 8,000,000 cycles
- - Mounting Style: Plate
- - Overall Dimensions: Depth 7.6 in, Height 10.04 in, Width 5.63 in
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Item: IEC Magnetic Contactor
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 81 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.28
- Package Width: 10.55
- Package Height: 9.92
- Package Weight: 14.09
