IEC Magnetic Contactor, 1NC/1NO, 100V-250V AC/DC, 4 P, Spring Type MPN:LC1G4004KUEN

• IEC Magnetic Contactor, 4-pole, spring-type terminal, TeSys Giga series.

  An IEC magnetic contactor is an electrically operated switching device rated for operation within the specified IEC standards. This unit is a single-phase, 4-pole device with a coil rated 100-250V AC/DC, plate mounting, and spring-type terminals. Includes auxiliary contacts as specified

• does not contain an integrated surge suppression device.

  - Coil Voltage: 100V-250V AC/DC

• - Contactor Style: IEC
• - Phase: Single
• - Poles: 4
• - Auxiliary Contacts: 2 (Form 1NC/1NO)
• - Mounting Style: Plate
• - Terminal Connection Type: Spring Type
• - Rated for operation up to: 1000V AC within specified conditions
• - IP Rating: IP20
• - Frequency: 50/60 Hz
• - Maximum Operating Temperature: 140 Degrees F
• - Minimum Operating Temperature: -13 Degrees F
• - Mechanical Lifespan: Approximately 8 million cycles under normal use conditions
• - Overall Dimensions: Depth 4.8 in, Height 8.86 in, Width 7.28 in
• - Full Load Amps (Inductive/Resistive): 490 A / 550 A → Rated for continuous current loads up to 490 A (Inductive) / 550 A (Resistive) within specified parameters
• - Full Load Current (Inductive/Resistive): 400 A / 550 A → Rated for continuous current loads up to 400 A (Inductive) / 550 A (Resistive) within specified parameters
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
• - Embedded Surge Suppressor: No
• - Item: IEC Magnetic Contactor
