IEC Magnetic Contactor, 1NC/1NO, 200V-500V AC/DC, 3 P, Spring Type MPN:LC1G150LSEA

• The Schneider Electric IEC Magnetic Contactor is an electrically operated Switching device rated for operation within specified parameters. It is a 3-pole unit with 2 auxiliary contacts configured as 1NC/1NO, and it uses a coil voltage range of 200–500 V (AC/DC) with spring-type terminals mounted on a plate. This IEC-style contactor is rated for operation at 50/60 Hz frequency, conforms to IP20 ingress protection standards, and rated for use within voltage levels up to 1000 V AC. It is part of the TeSys Giga series and is compatible with single-phase electrical systems, with a mechanical lifespan up to 8,000,000 cycles under specified conditions. It is designed to operate within the specified temperature range from -13°F to 140°F.

  Key features

• - Auxiliary contacts: 2 total (1NC/1NO)
• Includes Auxiliary Contacts: Yes
• Number of Auxiliary Contacts: 2
• - Coil voltage: 200–500 V AC/DC
• - Contactor style: IEC
• - Embedded surge suppressor: No
• - Frequency: 50/60 Hz
• - Full Load Amps-Inductive: 230 A
• - Full Load Amps-Resistive: 275 A
• - Full Load Current - Inductive: 150 A
• - Full Load Current - Resistive: 275 A
• - IP Rating: IP20
• - Mounting Style: Plate
• - Maximum Operating Temperature: 140 Degrees F
• - Minimum Operating Temperature: -13 Degrees F
• - Maximum Voltage Rating: 1000V AC
• - Mechanical Operating Durability: 8000000
• - Phase: Single
• - Series: TeSys Giga
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
• - Terminal Connection Type: Spring Type
• - Item: IEC Magnetic Contactor
• - Overall Dimensions: Depth 7.6 in, Height 10.04 in, Width 4.25 in
