Spring plunger MPN:10.01.02.00608
The SCHMALZ 10.01.02.00608 vacuum buffer is a versatile and reliable solution for stabilizing vacuum pressure in pneumatic systems. Its rotating buffer head provides flexibility in positioning, making it ideal for applications where vacuum demand is intermittent or pulsed. This compact and lightweight device operates within a wide temperature range and features a spring force of 4.36 N, with a stroke length of 10 mm. Perfect for use in manufacturing, packaging, and material handling industries, the 10.01.02.00608 ensures consistent vacuum performance, reducing downtime and increasing productivity. Its compact size and ease of installation make it an excellent choice for a wide range of applications.
Top product features:
- Rotating buffer head
- Stores and stabilizes vacuum pressure during intermittent or pulsed demand
- Operates within a temperature range from 0 to 80 Degrees C
Top product applications:
- Vacuum lift systems for handling and processing of lightweight materials
- Pneumatic vacuum systems for material handling and processing
- Assembly and inspection stations for electronic components
The SCHMALZ - 10.01.02.00608 is a vacuum buffer designed for integration into pneumatic vacuum systems. It stores and stabilizes vacuum pressure during intermittent or pulsed demand. This model features a rotating buffer head, offering flexibility in positioning. It operates within a temperature range from 0 to 80 Degrees C and is part of the FSTE series. Key Features:
- - Rotating buffer head.
- - External mounting screw and thread size: 1/8 in.
- - Pad end port: Female, size M5, with metric thread type.
- - Vacuum end port: Female, size M5, metric thread type.
- - Spring force: 4.36 N
- spring rate: 0.32 N/mm
- - Stroke length: 10 mm
- - Overall length of 47.2 mm and outside diameter of 1/8 in.
- - Mass: 19 g
Additional Information
- Country of Origin: DE
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.90
- Package Width: 4.60
- Package Height: 1.20
- Package Weight: 0.32
