Bellow Suction cup for Sheet handling MPN:10.01.06.00674
Bellow Suction cup for Sheet handling
The SCHMALZ Bellow Suction Cup for Sheet handling is a reliable and efficient solution for handling sheet metal. Its durable aluminum construction and NBR pad with 60 Shore A hardness ensure secure grip and long-lasting performance. With a maximum vacuum pressure of -0.6 bar and 1.5 folds, this suction cup can handle a wide range of sheet metal applications. Ideal for industries such as manufacturing, construction, and metalworking, this suction cup provides a safe and easy way to lift and move heavy sheets. Its compact design and lightweight construction make it easy to integrate into existing systems.
Top product features:
- Vacuum Pad Assembly is designed for handling sheet metal.
- Pad is made of NBR material with a hardness of 60 Shore A.
- Pad is a bellows type with a stroke of 14.5 mm.
Top product applications:
- Sheet Metal Handling
- Sheet Handling
- Vacuum Conveyance of Sheets
Item Vacuum Pad Assembly, Adapter Material Aluminum, Durometer 60 A, For Use With Handling Sheet Metal, Maximum Vacuum Pressure -0.6 bar, Number of Folds 1.5, Outside Diameter 60 mm, Overall Height 56.3 mm, Pad Color Blue, Pad Diameter 67 mm, Hardness 60 Shore A, Pad Height 41.3 mm, Pad Material NBR, Pad Type Bellows, Port Size 3/8 in, Port Type G, Series SAB, Standards DIN ISO 3302-1 M3, Stroke 14.5 mm, Weight 40 g
Additional Information
- Country of Origin: DE
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 10.20
- Package Width: 9.00
- Package Height: 3.20
- Package Weight: 0.56
