Spring plunger with internal spring MPN:10.01.02.01474
The SCHMALZ 10.01.02.01474 is a versatile vacuum buffer designed for use in pneumatic systems, providing a rotating buffer to allow swivel motion during operation. Its electrically insulating properties make it suitable for a wide range of applications, including those requiring high precision and safety. The buffer's compact size and lightweight design make it easy to integrate into existing systems, while its temperature range of 0-80°C ensures reliable performance in various environments. Ideal for use in manufacturing, laboratory, and cleanroom settings, this buffer helps to dampen vacuum pressure fluctuations, reducing wear and tear on equipment and improving overall system efficiency.
Top product features:
- Rotating design allows pivotal movement during use.
- Dampens vacuum pressure fluctuations.
- Features a female thread port at both vacuum and pad ends, sized M5 metric.
Top product applications:
- Vacuum systems in semiconductor manufacturing
- Pneumatic systems in medical equipment
- Industrial vacuum systems for cleanrooms
The SCHMALZ - 10.01.02.01474 is a vacuum buffer used in pneumatic systems to dampen vacuum pressure fluctuations. It features a rotating buffer to allow swivel motion during operation. The component is electrically insulating and suitable for operating temperatures between 0 and 80 Degrees C. It is part of the FSTIm series and supports metric connection standards with female thread ports sized M5 at both vacuum and pad ends.
Key Features:
- - Buffer Rotation: Rotating design allows pivotal movement during use.
- - Operating Temperature Range: 0 to 80 Degrees C.
- - External Mounting: Uses M10 screws with a 1 mm thread pitch and M10 thread size.
- - Connection Ports: Female gender at vacuum end and pad end, both M5 metric ports.
- - Size Specifications: Overall length of 54.4 mm and outside diameter of 10 mm.
- - Spring Properties: Spring force of 0.75 N and spring rate of 0.05 N/mm.
- - Hex Sizes: 8 mm and 14 mm wrench interface dimensions.
- - Weight: 18.5 g.
- - Compliance Standard: ISO 14644-1.
Additional Information
- Country of Origin: DE
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.00
- Package Width: 1.00
- Package Height: 0.70
- Package Weight: 0.30
