SHAFT COLLAR QUICK CLAMPING MPN:LVO-MCL-7E-AN
SHAFT COLLAR QUICK CLAMPING
The Ruland Quick Clamping Shaft Collar is a versatile and reliable component ideal for applications requiring easy installation and adjustment. Its aluminum construction and corrosion-resistant properties make it suitable for use in harsh environments. With a bore diameter of 7/16 in and outside diameter of 28 mm, this collar can be used in a variety of settings, including machinery, equipment, and automation systems. Its compact size and lightweight design also make it an excellent choice for applications where space and weight are limited, such as in robotics and medical devices.
Top product features:
- Quick clamping mechanism allows for rapid installation and removal of the shaft collar.
- Aluminum construction provides corrosion-resistance.
- Keyless design eliminates the need for a keyway.
Top product applications:
- Shaft collars are used to mount and secure loads on a shaft in applications such as conveyor systems.
- Shaft collars are used in mechanical systems to provide a secure and adjustable mounting point for pulleys and idlers.
- Shaft collars are used in robotics and automation to provide a precise and repeatable mounting point for mechanical components.
Quick Clamping Shaft Collar, System of Measurement Metric with Inch Bore, Bore Type Round, Bore Diameter 7/16 in, Bore Thread Size Not Applicable, Collar Outside Diameter 28 mm, Inside Height to Flat Not Applicable, Collar Width 13 mm, Collar Material Aluminum, Keyway Width Not Applicable, Collar Material Grade 2024, Keyway Depth Not Applicable, Center to Lever Top 32.2 mm, Collar Construction 1-Piece, Screw Material Stainless Steel, Resistance Properties Corrosion-Resistant
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.00
- Package Width: 6.00
- Package Height: 1.00
- Package Weight: 0.10
Product info last updated on March 18, 2026 11:24am UTC
Category: Bearings, V-belts and Power Transmission Equipment
