Shaft Collar, 1pc Clamp, Bore 7mm, OD18mm, 316 Stainless Steel, MSP-7-ST MPN:MSP-7-ST
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3406964
Shaft Collar, 1pc Clamp, Bore 7mm, OD18mm, 316 Stainless Steel, MSP-7-ST
The Ruland MSP-7-ST Shaft Collar is a precision-engineered component ideal for applications requiring high holding power and precise alignment. Its two-piece design allows for in-place installation and servicing, minimizing downtime and reducing the risk of shaft damage. The 316 stainless steel construction ensures consistent corrosion resistance, making it suitable for use in harsh environments. This shaft collar is perfect for use in load-bearing applications, as a mechanical stop, or for component alignment in industries such as aerospace, medical devices, and precision machinery. Its fine burr-free finish and tightly controlled face-to-bore perpendicularity ensure reliable performance and long lifespan.
Top product features:
- The collar is infinitely adjustable.
- The collar does not mar the shaft.
- The collar has superior holding power when compared to set screw collars.
Top product applications:
- Load bearing face
- Mechanical stop
- Component alignment
Ruland clamp style shaft collars do not mar the shaft, are infinitely adjustable, and have superior holding power when compared to set screw collars. This two-piece shaft collar has a 7mm bore, 18mm OD, and 9mm width. Tightly controlled face to bore perpendicularity is maintained (TIR of < 0.05mm) which is critical when the collar is used as a load bearing face, mechanical stop, or for component alignment. The work surface is identified by one groove on the face allowing the user to easily identify which side is precision faced. The two-piece design allows this collar to be installed or serviced in-place without the need to remove adjacent components. Halves are mated throughout the manufacturing process for precise fit and increased holding power. This collar is stamped with the Ruland name and bore size for ease of identification. It is manufactured from 316 stainless steel to a fine burr-free finish with hardware of like material for consistent corrosion resistance. Hardware tests beyond DIN 912 12.9 standards for maximum holding power. It is RoHS and REACH compliant.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 2 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 5.00
- Package Height: 2.00
- Package Weight: 0.03
