Shaft Collar, 1pc Clamp, Bore 9mm, OD24mm, 316 Stainless Steel, MSP-9-ST MPN:MSP-9-ST
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3401784
Shaft Collar, 1pc Clamp, Bore 9mm, OD24mm, 316 Stainless Steel, MSP-9-ST
This Ruland shaft collar provides precision and reliability for a variety of applications, including load bearing faces, mechanical stops, and component alignment. Its two-piece design allows for in-place installation and servicing, minimizing downtime and disruption. The clamp style collar features a 9mm bore, 24mm OD, and 9mm width, with tightly controlled face to bore perpendicularity and a fine burr-free finish. Manufactured from 316 stainless steel, it offers superior corrosion resistance and holding power, making it ideal for use in harsh environments and demanding applications such as robotics, medical devices, and industrial automation.
Top product features:
- The two-piece shaft collar design allows for in-place installation or servicing without removing adjacent components.
- The collar has tightly controlled face to bore perpendicularity, maintaining a tolerance of less than 0.05mm.
- The design features a precision faced work surface, identified by a single groove on the face, allowing for easy identification of the precision faced side.
Top product applications:
- Shaft alignment in precision machinery
- Load bearing face in high-precision applications
- Mechanical stop in robotic assembly systems
Ruland clamp style shaft collars do not mar the shaft, are infinitely adjustable, and have superior holding power when compared to set screw collars. This two-piece shaft collar has a 9mm bore, 24mm OD, and 9mm width. Tightly controlled face to bore perpendicularity is maintained (TIR of < 0.05mm) which is critical when the collar is used as a load bearing face, mechanical stop, or for component alignment. The work surface is identified by one groove on the face allowing the user to easily identify which side is precision faced. The two-piece design allows this collar to be installed or serviced in-place without the need to remove adjacent components. Halves are mated throughout the manufacturing process for precise fit and increased holding power. This collar is stamped with the Ruland name and bore size for ease of identification. It is manufactured from 316 stainless steel to a fine burr-free finish with hardware of like material for consistent corrosion resistance. Hardware tests beyond DIN 912 12.9 standards for maximum holding power. It is RoHS and REACH compliant.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 2 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 5.00
- Package Height: 2.00
- Package Weight: 0.05
Product info last updated on February 9, 2026 9:18pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
