Shaft Collar, 1pc Clamp, Bore 42mm, OD73mm, 316 Stainless Steel, MSP-42-ST MPN:MSP-42-ST
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3399124
Shaft Collar, 1pc Clamp, Bore 42mm, OD73mm, 316 Stainless Steel, MSP-42-ST
Ruland's MSP-42-ST shaft collar is a precision-engineered two-piece clamp style collar ideal for applications where a load bearing face or mechanical stop is required. Its tightly controlled face to bore perpendicularity ensures accurate alignment and holding power. Made from 316 stainless steel, this collar provides consistent corrosion resistance and meets or exceeds DIN 912 12.9 standards for maximum holding power. Suitable for use in industries such as aerospace, medical, and food processing, this collar is also infinitely adjustable, allowing for easy installation or servicing in-place without removing adjacent components. It is RoHS and REACH compliant.
Top product features:
- Tightly controlled face to bore perpendicularity is maintained (TIR of < 0.05mm) which is critical when the collar is used as a load bearing face, mechanical stop, or for component alignment.
- The two-piece design allows this collar to be installed or serviced in-place without the need to remove adjacent components.
- Halves are mated throughout the manufacturing process for precise fit and increased holding power.
Top product applications:
- Shaft alignment in precision machinery
- Load bearing face in high-precision applications
- Mechanical stop in automation systems
Ruland clamp style shaft collars do not mar the shaft, are infinitely adjustable, and have superior holding power when compared to set screw collars. This two-piece shaft collar has a 42mm bore, 73mm OD, and 19mm width. Tightly controlled face to bore perpendicularity is maintained (TIR of < 0.05mm) which is critical when the collar is used as a load bearing face, mechanical stop, or for component alignment. The work surface is identified by one groove on the face allowing the user to easily identify which side is precision faced. The two-piece design allows this collar to be installed or serviced in-place without the need to remove adjacent components. Halves are mated throughout the manufacturing process for precise fit and increased holding power. This collar is stamped with the Ruland name and bore size for ease of identification. It is manufactured from 316 stainless steel to a fine burr-free finish with hardware of like material for consistent corrosion resistance. Hardware tests beyond DIN 912 12.9 standards for maximum holding power. It is RoHS and REACH compliant.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 2 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 5.00
- Package Height: 2.00
- Package Weight: 0.85
Product info last updated on January 29, 2026 5:54pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
