Keyed Collar, 1pc Clamp, Bore 45mm, OD 73mm, Steel MPN:MSPK-45-F
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3394766
Keyed Collar, 1pc Clamp, Bore 45mm, OD 73mm, Steel
This keyed shaft collar offers superior holding power and precise fit for keyed shafting applications. Its two-piece design allows for in-place installation or servicing without removing adjacent components. The collar's tightly controlled face to bore perpendicularity and fine burr-free finish ensure reliable performance in load-bearing, mechanical stop, and component alignment applications. Made from 1215 lead-free steel with a proprietary black oxide formulation, this collar provides increased holding power and corrosion resistance. It meets or exceeds DIN 912 12.9 standards and is RoHS and REACH compliant, making it a reliable choice for demanding industrial applications.
Top product features:
- Tightly controlled face to bore perpendicularity is maintained (TIR of < 0.05mm) which is critical when the collar is used as a load bearing face, mechanical stop, or for component alignment.
- The two-piece design allows this collar to be installed or serviced in-place without the need to remove adjacent components.
- Halves are mated throughout the manufacturing process for precise fit and increased holding power.
Top product applications:
- Positive drive applications where a secure connection is required
- Load bearing face applications where high precision is necessary
- Mechanical stop applications where precise alignment is critical
Ruland clamp style shaft collars do not mar the shaft, are infinitely adjustable, and have superior holding power when compared to set screw collars. This two-piece keyed shaft collar has a 45mm bore, 14mm keyway, 73mm OD, and 19mm width. It is designed for use with keyed shafting and in applications where the collar may be used for positive drive. Tightly controlled face to bore perpendicularity is maintained (TIR of < 0.05mm) which is critical when the collar is used as a load bearing face, mechanical stop, or for component alignment. The work surface is identified by two grooves on the face allowing the user to easily identify which side is precision faced. The two-piece design allows this collar to be installed or serviced in-place without the need to remove adjacent components. Halves are mated throughout the manufacturing process for precise fit and increased holding power. This collar is stamped with the Ruland name and bore size for ease of identification. It is manufactured from 1215 lead-free steel to a fine burr-free finish with Ruland's proprietary black oxide formulation which creates a fine glossy appearance and increases holding power and corrosion resistance. Hardware tests beyond DIN 912 12.9 standards for maximum holding power. It is RoHS and REACH compliant.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 2 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 5.00
- Package Height: 1.00
- Package Weight: 0.75
Product info last updated on February 28, 2026 8:18pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
