Shaft Collar, Clamp, 2Pc, 1/4 In, Alum MPN:MSP-4E-AN
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1966548
Shaft Collar, Clamp, 2Pc, 1/4 In, Alum
This Ruland Shaft Collar is a precision-engineered 2-piece clamp designed for secure shaft attachment. Made from durable aluminum alloy 2024, it features a round bore diameter of 1/4 inch and a wide range of applications in various industries. Its compact size, measuring 18mm in outside diameter and 9mm in width, makes it ideal for use in tight spaces. The shaft collar's 2-piece construction and stainless steel screws ensure a strong and reliable hold, while its metric with inch bore design provides versatility. Suitable for use in robotics, automation, and other precision machinery applications.
Top product features:
- Two-piece construction allows for easy installation and removal
- Made from aluminum for corrosion resistance and light weight
- Keyway width is not applicable, allowing for use in applications where a keyway is not required
Top product applications:
- Shaft Collar applications:
- Positioning and locating shafts in applications where a secure, non-slip fit is required
- Acting as a stop or a lock to prevent shaft rotation in applications such as gearboxes and motors
Shaft Collar, System of Measurement Metric with Inch Bore, Bore Type Round, Bore Diameter 1/4 in, Bore Thread Size Not Applicable, Collar Outside Diameter 18 mm, Inside Height to Flat Not Applicable, Clearance Diameter 22.4 mm, Collar Width 9 mm, Collar Material Aluminum, Keyway Width Not Applicable, Collar Material Grade 2024, Keyway Depth Not Applicable, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 2-Piece, Screw Material Stainless Steel
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.00
- Package Width: 3.00
- Package Height: 0.40
- Package Weight: 0.01
Product info last updated on January 30, 2026 10:05pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
