Jaw Parallel Gripper, Series Rth 3 MPN:RTH-7M-L
Jaw Parallel Gripper, Series Rth 3
The ROBOHAND Jaw Parallel Gripper, Series RTH 3, is a robust and reliable solution for gripping and handling various materials in industrial settings. Its parallel jaw design allows for precise and stable grasping, while its high operating pressure and force capabilities make it suitable for heavy-duty applications. With a wide temperature range and IP55 rating, it can withstand harsh environments. This gripper is ideal for use in robotics, automation, and manufacturing, particularly in industries such as metalworking, woodworking, and packaging. Its compact size and ease of integration make it a versatile tool for various applications, including assembly, inspection, and material handling.
Top product features:
- Parallel jaw design allows for even gripping pressure and secure holding of objects.
- Carbon steel fingers provide high strength and durability in the gripper's fingers.
- Maximum operating pressure of 100 psi enables the gripper to handle heavy loads and objects with high friction requirements.
Top product applications:
- Automotive manufacturing: The Jaw Parallel Gripper can be used to assemble and disassemble parts in automotive manufacturing, such as gripping and placing engine components.
- Robotics and automation: The gripper can be integrated into robotic systems to perform tasks that require precise gripping and manipulation of objects, such as picking and placing small parts.
- Medical device assembly: The gripper can be used in medical device manufacturing to assemble and test medical devices, such as surgical instruments and diagnostic equipment.
Parallel Jaw Gripper, Series RTH, Open Width 210 mm, Stroke Length 50 mm, Maximum Operating Pressure 100 psi, Minimum Operating Pressure 29 psi, Overall Length 143 mm, Overall Width 210 mm, Overall Height 143 mm, Body Material Aluminum, Finger Material Carbon Steel, Inlet Size M5, Maximum Operating Temperature 80 Degrees C, Minimum Operating Temperature -35 Degrees C, Weight 15.7 kg, System of Measurement Metric, Total Rated Grip Force @ 100 psi 11,102 N, IP Rating IP55, Seal Material Buna-N
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on March 20, 2026 3:28am UTC
Category: Compressors, Air Tanks and Pneumatic Parts
